Sony HDR-FX7 User Manual

— 7 —
HDR-FX7/FX7E_L2
TABLE OF CONTENTS
1. SERVICE NOTE
1-1. Power Supply During Repairs ·········································1-1
1-2. To Take Out a Cassette when not Eject (Force Eject) ····· 1-1
1-3. Setting the “Forced Power On” Mode ·····························1-1
1-4. Using Service Jig ····························································· 1-2
1-5. Self-diagnosis Function ···················································1-2
1-6. Method of Coping with Shift Lens Error ························1-4
2. DISASSEMBLY
2-1. Disassembly····································································· 2-2
2-2. Method of Lens Unit Disassembly ··································2-9
3. BLOCK DIAGRAMS
3-1. Overall Block Diagram (1/8) ···········································3-1
3-2. Overall Block Diagram (2/8) ···········································3-2
3-3. Overall Block Diagram (3/8) ···········································3-3
3-4. Overall Block Diagram (4/8) ···········································3-4
3-5. Overall Block Diagram (5/8) ···········································3-5
3-6. Overall Block Diagram (6/8) ···········································3-6
3-7. Overall Block Diagram (7/8) ···········································3-7
3-8. Overall Block Diagram (8/8) ···········································3-8
3-9. Power Block Diagram (1/4)············································· 3-9
3-10. Power Block Diagram (2/4)··········································· 3-10
3-11. Power Block Diagram (3/4)··········································· 3-11
3-12. Power Block Diagram (4/4)··········································· 3-12
4. PRINTED WIRING BOARDS AND
SCHEMATIC DIAGRAMS
4-1. Frame Schematic Diagrams············································· 4-1
4-2. Schematic Diagrams ························································ 4-3
4-3. Printed Wiring Boards ···················································4-43
4-4. Mounted Parts Location ················································ 4-65
5. REPAIR PARTS LIST
5-1. Exploded Views ······························································· 5-2
5-2. Electrical Parts List ······················································· 5-17
Section Title Page

Sony HDR-FX7 Specifications

General

Built-in display	Yes
Display diagonal	3.5 \
Display resolution (numeric)	211000 pixels
Filter size	62 mm
Digital zoom	- x
Optical zoom	20 x
Focal length range	3.9 - 78 mm
Interchangeable lens	-
Maximum aperture number	2.8
Minimum aperture number	1.6
Focal length (35mm film equivalent)	37.4 - 748 mm
Maximum focal length (35mm film equiv)	748 mm
Minimum focal length (35mm film equiv)	37.4 mm
Sensor type	CMOS
Total megapixels	1.07 MP
Optical sensor size	1/4 \
Camcorder tape type	HDV
Camcorder media type	Videotape
Compatible memory cards	MS PRO
Internal storage capacity	- GB
S-Video in	No
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Focus adjustment	Auto/Manual
Camera shutter speed	1/3 - 1/10000 s
Camcorder type	Shoulder camcorder
Minimum illumination	4 lx
Supported aspect ratios	4:3, 16:9
Product color	Black
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Maximum image resolution	1440 x 810 pixels
Audio system	stereo
Battery capacity	- mAh
Battery life (max)	8 h
Cables included	AV, USB
Aperture range (F-F)	1.6 - 2.8

Weight and Dimensions

Depth	322 mm
Width	145 mm
Height	156 mm
Weight	1400 g
