Sony HXR-NX5C - Exploded View - Chassis Section; Disassembly Instructions - Chassis Section

HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
2-5
Ref. No. Part No. Description Ref. No. Part No. Description
101 4-119-234-11 WASHER, TRIPOD
* 102 4-165-251-01 CHASSIS, MAIN
103 4-119-237-01 PLATE (F), MC FIXED
* 104 4-165-225-01 SHEET (3218T1), RADIATION
105 4-165-224-01 SHEET (6018T1), RADIATION
#49 2-630-005-31 SCREW (M2), NEW TRUSTER, P2
#119 7-627-556-58 SCREW +P 2.6X5
2-1-3. CHASSIS SECTION
Screw
#49: M2.0 X 4.0
(Black)
2-630-005-31
4.0
2.0
DISASSEMBLY
5 #119 X 4
#119
Top View
6 #119 X 4
#119
#119
Left View
7 #49 X 5
5 Handle Section-1
(See page 2-9)
#119
#119
#119
#49
105
#49
#49
6 Lens Section
(See page 2-16)
7 BT Panel Section
(See page 2-17)
8 102
101
103
104
1. Remove to numerical order (5 to 8) in the left figure.
2. The meaning of the sign in left figure is as follows. Be careful when it removes.
#49
#49
Back View Right View
#119: M2.6 X 5.0
(Black)
7-627-556-58
5.0
2.6
