HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
SPECIFICATIONS
– ENGLISH – – ENGLISH –
SPECIFICATIONS
System
Video signal
PAL color, CCIR standards
HDTV 1080/50i, 720/50p
Video recording system
HD image quality: MPEG-4 AVC/
H.264 AVCHD
SD image quality: MPEG-2 PS
Audio recording system
Linear PCM 2ch (48 kHz 16-bit)
Dolby Digital 2ch (48 kHz 16-bit)
Dolby Digital Stereo Creator employed
Still image recording system
DCF Ver. 2.0
Exif Ver. 2.21
MPF Baseline
Recording media (movies/still images)
“Memory Stick PRO Duo” media Flash memory
units
SD memory cards, SDHC memory cards
(Class 4, 6, 10)
Viewfinder
Electric viewfinder (color, black and white)
Picture: 1.1 cm (0.45 type, aspect ratio 16:9)
Total dot number:
1 226 880 (approx. 852 × 3 [RGB] × 480)
Image device
6.0 mm (1/3 type) 3CMOS sensor
Gross: Approx. 1 120 000 pixels
Effective (movie, 16:9):
Approx. 1 040 000 pixels*
Effective (movie, 4:3):
Approx. 780 000 pixels*
Lens
G Lens
20 × (Optical), Approx. 30 × (Digital, when
[D.EXTENDER] is set to [ON])
Focal length
f=4.1 - 82.0 mm (3/16 - 3 1/4 in.)
When converted to a 35 mm still camera*
29.5 - 590 mm (1 3/16 - 23 1/4 in.)
(16:9),
36.1 - 722 mm (1 7/16 - 28 1/2 in.)
(4:3)
F1.6 - 3.4
Filter diameter: 72 mm (2 7/8 in.)
Color temperature
[AUTO]
(one push) A/B
[INDOOR] (3 200K)
[OUTDOOR] (5 800K±7 offset levels)
[MANU WB TEMP] (2 300K -
15 000K in 100K steps)
Minimum illumination
1.5 lx (lux) (Fixed Shutter Speed 1/25,
auto gain, auto iris) (F 1.6)
* When [SET] of [STEADYSHOT] is set to
[STEADYSHOT] or [OFF]
Output connectors
VIDEO OUT jack
Pin connector
1 Vp-p, 75 Ω (ohms) unbalanced, sync
negative
AUDIO OUT jacks
Pin connectors
-10 dBu (at load impedance 47 kΩ (kilohms)),
Output impedance with less than 2.2 kΩ
(kilohms) (0 dBu = 0.775 Vrms)
COMPONENT OUT jack
Mini-D jack
Y: 1 Vp-p, 75 Ω (ohms)
PB/PR, CB/CR: 0.7 Vp-p, 75 Ω (ohms)
HDMI OUT jack
HDMI connector
SDI OUT jack
BNC
SMPTE292M/259M
i (headphones) jack
Stereo-minijack (Ø 3.5 mm)
Input connectors
INPUT1/INPUT2 jacks
XLR 3-pin, female,
MIC: -48 dBu: 3 kΩ (kilohms)
(Variable in the range of between
-60 dBu and -30 dBu in 6 dB step by the INPUT
TRIM function)
LINE: +4 dBu: 10 kΩ (kilohms)
(0 dBu = 0.775 Vrms)
Input/Output connectors
USB jack
mini-B
Remote jack
Stereo mini-minijack (Ø 2.5 mm)
TC LINK IN/OUT jack
Pin connector
IN: 0.5 V to 18 Vp-p, 10 kΩ (kilohms)
OUT: 1.2 Vp-p, 75 Ω (ohms)
(IN/OUT switch-able)
LCD screen
8.0 cm (3.2 type, aspect ratio 16:9)
Total dot number
921 600 (1 920 × 480)
General
Power requirements
DC 7.2 V (battery pack)
DC 8.4 V (AC Adaptor/Charger)
Average power consumption*
HXR-NX5E/NX5P
During camera recording using the microphone
ECM-XM1 and viewfinder with normal
brightness: 7.7 W
During camera recording using the microphone
ECM-XM1 and LCD with normal brightness:
7.7 W
HXR-NX5M
During camera recording using the microphone
ECM-XM1 and viewfinder with normal
brightness: 7.4 W
During camera recording using the microphone
ECM-XM1 and LCD with normal
brightness: 7.4 W
* When Flash Memory Unit HXR-FMU128 is used,
the average power consumption increases about
1.1 W.
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
173 × 193 × 449 mm
(6 7/8 × 7 5/8 × 17 3/4 in.) (w/h/d)
including the projecting parts
173 × 193 × 449 mm
(6 7/8 × 7 5/8 × 17 3/4 in.) (w/h/d)
including the projecting parts with the battery
pack (NP-F570)
Mass (approx.)
2.2 kg (4 lb 15 oz) including the lens hood with
lens cover 2.5 kg (5 lb 7 oz) including the
battery pack (NP-F570), lens hood with lens
cover and microphone (ECM-XM1)
AC Adaptor/Charger AC-VL1
Power requirements
AC 100 V - 240 V, 50 Hz/60 Hz
Power consumption
22 W
Output voltage
DC 8.4 V*
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
136 × 51 × 90 mm
(5 3/8 × 2 1/8 × 3 5/8 in.) (w/h/d)
excluding the projecting parts
Mass (approx.)
270 g (9.6 oz) excluding the power cord
(mains lead)
* See the label on the AC Adaptor/Charger for other
specifications.
Rechargeable battery pack NP-F570
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Maximum charge voltage
DC 8.4 V
Maximum charge current
3.0 A
Capacity
Typical: 15.8 Wh (2 200 mAh)
Minimum: 15.0 Wh (2 100 mAh)
Type
Li-ion
Design and specifications are subject to change
without notice.
• Manufactured under license from Dolby Labora-
tories.
System
Video signal
NTSC color, EIA standards
HDTV 1080/60i, 720/60p
Video recording system
HD image quality: MPEG-4 AVC/
H.264 AVCHD
SD image quality: MPEG-2 PS
Audio recording system
Linear PCM 2ch (48 kHz 16-bit)
Dolby Digital 2ch (48 kHz 16-bit)
Dolby Digital Stereo Creator employed
Still image recording system
DCF Ver. 2.0
Exif Ver. 2.21
MPF Baseline
Recording media (movies/still images)
“Memory Stick PRO Duo” media Flash memory
unit SD memory card, SDHC memory card
(Class 4, 6, 10)
Viewfinder
Electric viewfinder (color, black and white)
Picture: 1.1 cm (0.45 type, aspect ratio 16:9)
Total dot number:
1 226 880 (approx. 852 × 3 [RGB] × 480)
Image device
6.0 mm (1/3 type) 3CMOS sensor
Gross: Approx. 1 120 000 pixels
Effective (movie, 16:9):
Approx. 1 040 000 pixels*
Effective (movie, 4:3):
Approx. 780 000 pixels*
Lens
G Lens
20 × (Optical), Approx. 30 × (Digital, when
[D.EXTENDER] is set to [ON])
Focal length
f=4.1 - 82.0mm (3/16 - 3 1/4 in.)
When converted to a 35 mm still camera*
29.5 - 590 mm (1 3/16 - 23 1/4 in.) (16:9),
36.1 - 722 mm (1 7/16 - 28 1/2 in.) (4:3)
F1.6 - 3.4
Filter diameter: 72 mm (2 7/8 in.)
Color temperature
[AUTO]
(one push) A/B
[INDOOR] (3 200K)
[OUTDOOR] (5 800K±7 offset levels)
[MANU WB TEMP] (2 300K -
15 000K in 100K steps)
Minimum illumination
1.5 lx (lux) (Fixed Shutter Speed 1/30, auto gain,
auto iris) (F 1.6)
* When [SET] of [STEADYSHOT] is set to
[STEADYSHOT] or [OFF]
Output connectors
VIDEO OUT jack
Pin connector
1 Vp-p, 75 Ω (ohms) unbalanced, sync
negative
AUDIO OUT jacks
Pin connectors
-10 dBu (at load impedance 47 kΩ
(kilohms)), Output impedance with less than
2.2 kΩ (kilohms)
(0 dBu = 0.775 Vrms)
COMPONENT OUT jack
Mini-D jack
Y: 1 Vp-p, 75 Ω (ohms)
PB/PR, CB/CR: 0.7 Vp-p, 75 Ω (ohms)
HDMI OUT jack
HDMI connector
SDI OUT jack
BNC
SMPTE292M/259M
i (headphones) jack
Stereo-minijack (Ø 3.5 mm)
Input connectors
INPUT1/INPUT2 jacks
XLR 3-pin, female,
MIC: -48 dBu: 3 kΩ (kilohms)
(Variable in the range of between
-60 dBu and -30 dBu in 6 dB step by
the INPUT TRIM function)
LINE: +4 dBu: 10 kΩ (kilohms)
(0 dBu = 0.775 Vrms)
Input/Output connectors
USB jack
mini-B
Remote jack
Stereo mini-minijack (Ø 2.5 mm)
TC LINK IN/OUT jack
Pin connector
IN: 0.5 V to 18 Vp-p, 10 kΩ (kilohms)
OUT: 1.2 Vp-p, 75 Ω (ohms)
(IN/OUT switch-able)
LCD screen
8.0 cm (3.2 type, aspect ratio 16:9)
Total dot number
921 600 (1 920 × 480)
General
Power requirements
DC 7.2 V (battery pack)
DC 8.4 V (AC Adaptor/Charger)
Average power consumption*
During camera recording using the microphone
ECM-XM1 and viewfinder with normal bright-
ness: 7.9 W
During camera recording using the microphone
ECM-XM1 and LCD with normal brightness:
7.9 W
* When Flash Memory Unit HXR-FMU128 is used,
the average power consumption increases about
1.1 W.
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
173 × 193 × 449 mm
(6 7/8 × 7 5/8 × 17 3/4 in.) (w/h/d)
including the projecting parts
173 × 193 × 449 mm
(6 7/8 × 7 5/8 × 17 3/4 in.) (w/h/d)
including the projecting parts with battery pack
NP-F570
173 × 193 × 449 mm
(6 7/8 × 7 5/8 × 17 3/4 in.) (w/h/d)
including the projecting parts with
battery pack NP-F770
Mass (approx.)
2.2 kg (4 lb 15 oz) including the lens
hood with lens cover
2.5 kg (5 lb 7 oz) including battery pack
NP-F570, lens hood with lens cover and
microphone (ECM-XM1)
2.6 kg (5 lb 11 oz) including battery
pack NP-F770, lens hood with lens
cover and microphone (ECM-XM1)
AC Adaptor/Charger AC-VL1
Power requirements
AC 100 V - 240 V, 50 Hz/60 Hz
Power consumption
22 W
Output voltage
DC 8.4 V*
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (approx.)
136 × 51 × 90 mm
(5 3/8 × 2 1/8 × 3 5/8 in.) (w/h/d)
excluding the projecting parts
Mass (approx.)
270 g (9.6 oz) excluding the power cord
(mains lead)
* See the label on the AC Adaptor/Charger for other
specifications.
Rechargeable battery pack NP-F770
(supplied with HXR-NX5U)
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Maximum charge voltage
DC 8.4 V
Maximum charge current
3.0 A
Capacity
Typical: 31.7 Wh (4 400 mAh)
Minimum: 30.0 Wh (4 200 mAh)
Type
Li-ion
Rechargeable battery pack NP-F570
(supplied with HXR-NX5N)
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Maximum charge voltage
DC 8.4 V
Maximum charge current
3.0 A
Capacity
Typical: 15.8 Wh (2 200 mAh)
Minimum: 15.0 Wh (2 100 mAh)
Type
Li-ion
Design and specifications are subject to change
without notice.
• Manufactured under license from Dolby Labora-
tories.
These specifications are extracted from instruction manual of
HXR-NX5E/NX5M/NX5P.
These specifications are extracted from instruction manual of
HXR-NX5N/NX5U.
