HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
2-19
Ref. No. Part No. Description Ref. No. Part No. Description
A-1752-127-A AS-063 BOARD, COMPLETE
**********************
< CAPACITOR >
C1501 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1502 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1503 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1505 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1506 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C1507 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1508 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1509 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1510 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1511 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1512 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C1513 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C1514 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1515 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1516 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1517 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1518 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1519 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1520 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1521 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C1526 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1527 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1528 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN1501 1-817-920-11 CONNECTOR, FPC (ZIF) 80P
CN1502 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN1503 1-816-645-61 FFC/FPC CONNECTOR (LIF) 14P
< FERRITE BEAD >
* FB1501 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB1502 1-481-300-11 INDUCTOR, FERRITE BEAD
FB1503 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB1504 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB1505 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB1506 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB1507 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
< FILTER >
FL1501 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL1502 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC1501 6-713-638-01 IC BU19502KV-E2
IC1502 6-703-977-01 IC R1114Q331D-TR-FA
* IC1503 6-714-696-01 IC MAX8586ETA+T
< FILTER >
LF1501 1-457-374-21 COMMOM MODE CHOKE COIL
< RESISTOR >
R1501 1-218-940-11 METAL CHIP 82 5% 1/16W
R1502 1-218-940-11 METAL CHIP 82 5% 1/16W
R1503 1-218-940-11 METAL CHIP 82 5% 1/16W
R1504 1-218-940-11 METAL CHIP 82 5% 1/16W
R1505 1-218-940-11 METAL CHIP 82 5% 1/16W
R1506 1-218-933-11 METAL CHIP 22 5% 1/16W
R1507 1-218-940-11 METAL CHIP 82 5% 1/16W
R1508 1-218-933-11 METAL CHIP 22 5% 1/16W
R1509 1-218-940-11 METAL CHIP 82 5% 1/16W
R1510 1-218-940-11 METAL CHIP 82 5% 1/16W
R1511 1-218-933-11 METAL CHIP 22 5% 1/16W
R1512 1-218-935-11 METAL CHIP 33 5% 1/16W
R1513 1-218-935-11 METAL CHIP 33 5% 1/16W
R1514 1-218-935-11 METAL CHIP 33 5% 1/16W
R1515 1-218-935-11 METAL CHIP 33 5% 1/16W
R1516 1-218-935-11 METAL CHIP 33 5% 1/16W
R1517 1-218-935-11 METAL CHIP 33 5% 1/16W
R1518 1-218-935-11 METAL CHIP 33 5% 1/16W
R1519 1-218-935-11 METAL CHIP 33 5% 1/16W
R1520 1-218-935-11 METAL CHIP 33 5% 1/16W
R1521 1-218-935-11 METAL CHIP 33 5% 1/16W
R1522 1-218-935-11 METAL CHIP 33 5% 1/16W
R1523 1-218-935-11 METAL CHIP 33 5% 1/16W
R1524 1-218-935-11 METAL CHIP 33 5% 1/16W
R1525 1-218-935-11 METAL CHIP 33 5% 1/16W
R1526 1-218-935-11 METAL CHIP 33 5% 1/16W
R1527 1-218-935-11 METAL CHIP 33 5% 1/16W
R1528 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1532 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1533 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1534 1-208-890-11 METAL CHIP 1.3K 0.5% 1/16W
R1535 1-218-989-11 METAL CHIP 1M 5% 1/16W
R1536 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1545 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R1546 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1549 1-218-990-81 SHORT CHIP 0
R1551 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X1501 1-813-210-11 VIBRATOR, CRYSTAL (NX5032GA) (25MHz)
A-1752-112-A CK-218 BOARD, COMPLETE
**********************
< CONNECTOR >
* CN1001 1-779-335-51 CONNECTOR, FFC/FPC 22P
* CN1002 1-779-331-51 CONNECTOR, FFC/FPC 14P
CN1003 1-779-330-51 CONNECTOR, FFC/FPC 12P
* CN1004 1-817-560-71 CONNECTOR, FPC (ZIP) 21P
< RESISTOR >
R1001 1-218-970-11 METAL CHIP 27K 5% 1/16W
R1002 1-218-970-11 METAL CHIP 27K 5% 1/16W
R1003 1-218-970-11 METAL CHIP 27K 5% 1/16W
R1004 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R1005 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R1006 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R1007 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R1008 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
AS-063 CK-218
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some
differences from the original one.
• Items marked “*” are not stocked since they are seldom re-
quired for routine service. Some delay should be anticipated
when ordering these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may
be different from the parts specified in the diagrams or the
components used on the set.
• CAPACITORS:
uF: F
• COILS
uH: H
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: , for example:
uA...: A... , uPA... , PA... ,
uPB... , PB... , uPC... , PC... ,
uPD..., PD...
(JAPANESE)
The components identified by mark
or dotted line with mark are critical for
safety.
Replace only with part number speci-
fied.
Les composants identifiés par une mar-
que sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board name.
Caution
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
2-1. ELECTRICAL PARTS LIST
The changed portions from
Ver. 1.0 are shown in blue.
Ver. 1.1 2010.01
ノート:
Note: Replace the battery holder (BH2001) together
when replacing the lithium storage battery
(BT2001) on the GC-012 board. (The battery
holder removed once cannot be used again.)
When mounting these parts, mount new battery
holder first and attach new lithium storage
battery next.
To Next Page
