Sony HXR-NX5C - Electrical Parts List (Transistors, Resistors - XL-011 Board)

HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
Ref. No. Part No. Description Ref. No. Part No. Description
Ref. No. Part No. Description Ref. No. Part No. Description
* Q5806 6-551-625-01 TRANSISTOR RN2104MFV (TL3SONY)
Q5807 6-550-356-01 TRANSISTOR MCH6616-TL-E
Q5808 8-729-044-37 TRANSISTOR LSK3019FP8TL
Q5809 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)
Q5903 6-551-294-01 TRANSISTOR MCH6606-TL-E
Q5904 6-551-294-01 TRANSISTOR MCH6606-TL-E
Q5905 6-551-622-01 TRANSISTOR 2SC6026MFV (TL3SONY)
* Q5906 6-551-625-01 TRANSISTOR RN2104MFV (TL3SONY)
Q5907 6-550-356-01 TRANSISTOR MCH6616-TL-E
Q5908 8-729-044-37 TRANSISTOR LSK3019FP8TL
Q5909 6-551-631-01 TRANSISTOR RN1104MFV (TL3SONY)
Q5953 8-729-044-37 TRANSISTOR LSK3019FP8TL
Q5954 8-729-048-72 TRANSISTOR 2SK2615
 Q5955 6-551-622-01 TRANSISTOR 2SC6026MFV (TL3SONY)
Q5956 6-551-622-01 TRANSISTOR 2SC6026MFV (TL3SONY)
Q5957 6-551-622-01 TRANSISTOR 2SC6026MFV (TL3SONY)
 Q5958 8-729-119-64 TRANSISTOR 2SA811A-C17
 Q5959 8-729-119-64 TRANSISTOR 2SA811A-C17
< RESISTOR >
R5801 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5802 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5803 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5804 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5805 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R5806 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5807 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5808 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R5809 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5810 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5811 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5812 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5813 1-216-817-11 METAL CHIP 470 5% 1/10W
R5814 1-216-817-11 METAL CHIP 470 5% 1/10W
R5815 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R5816 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R5817 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
R5818 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
R5821 1-218-835-11 METAL CHIP 330 0.5% 1/10W
R5822 1-218-860-11 METAL CHIP 3.6K 0.5% 1/10W
R5823 1-218-835-11 METAL CHIP 330 0.5% 1/10W
R5824 1-218-860-11 METAL CHIP 3.6K 0.5% 1/10W
R5825 1-216-797-11 METAL CHIP 10 5% 1/10W
R5826 1-216-797-11 METAL CHIP 10 5% 1/10W
R5832 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5833 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5834 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5835 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5836 1-218-981-91 METAL CHIP 220K 5% 1/16W
R5837 1-218-981-91 METAL CHIP 220K 5% 1/16W
R5838 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5839 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5840 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5841 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R5842 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5843 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5851 1-218-901-11 METAL CHIP 180K 0.5% 1/10W
R5852 1-218-901-11 METAL CHIP 180K 0.5% 1/10W
R5853 1-218-901-11 METAL CHIP 180K 0.5% 1/10W
R5854 1-218-901-11 METAL CHIP 180K 0.5% 1/10W
R5855 1-218-878-11 METAL CHIP 20K 0.5% 1/10W
R5856 1-218-878-11 METAL CHIP 20K 0.5% 1/10W
R5857 1-218-878-11 METAL CHIP 20K 0.5% 1/10W
R5858 1-218-878-11 METAL CHIP 20K 0.5% 1/10W
R5859 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R5860 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R5861 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R5862 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R5863 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5864 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5865 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5866 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5867 1-216-797-11 METAL CHIP 10 5% 1/10W
R5868 1-216-797-11 METAL CHIP 10 5% 1/10W
R5901 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5902 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5903 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5904 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5905 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R5906 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5907 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5908 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R5909 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5910 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5911 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5912 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
R5913 1-216-817-11 METAL CHIP 470 5% 1/10W
R5914 1-216-817-11 METAL CHIP 470 5% 1/10W
R5915 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R5916 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R5917 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
R5918 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
R5921 1-218-835-11 METAL CHIP 330 0.5% 1/10W
R5922 1-218-835-11 METAL CHIP 330 0.5% 1/10W
R5923 1-218-860-11 METAL CHIP 3.6K 0.5% 1/10W
R5924 1-218-860-11 METAL CHIP 3.6K 0.5% 1/10W
R5925 1-216-797-11 METAL CHIP 10 5% 1/10W
R5926 1-216-797-11 METAL CHIP 10 5% 1/10W
R5932 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5933 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5934 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5935 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5936 1-218-981-91 METAL CHIP 220K 5% 1/16W
R5937 1-218-981-91 METAL CHIP 220K 5% 1/16W
R5938 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5939 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5940 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5941 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R5942 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5943 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5960 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5961 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R5962 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5963 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R5964 1-208-955-11 METAL CHIP 680K 0.5% 1/16W
R5965 1-208-944-81 METAL CHIP 240K 0.5% 1/16W
R5966 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5967 1-218-970-11 METAL CHIP 27K 5% 1/16W
R5968 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5969 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5970 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5971 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5972 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5973 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5974 1-216-849-11 METAL CHIP 220K 5% 1/10W
R5975 1-216-849-11 METAL CHIP 220K 5% 1/10W
R5976 1-208-894-81 METAL CHIP 2K 0.5% 1/16W
R5981 1-216-817-11 METAL CHIP 470 5% 1/10W
R5982 1-216-817-11 METAL CHIP 470 5% 1/10W
R5983 1-216-817-11 METAL CHIP 470 5% 1/10W
R5984 1-216-817-11 METAL CHIP 470 5% 1/10W
R5985 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5986 1-218-977-11 METAL CHIP 100K 5% 1/16W
XL-011
2-30E
The changed portions from
Ver. 1.0 are shown in blue.
Ver. 1.1 2010.01
