Page #212 background imageLoading...
Page #212 background image
212
The internal format converter function is enabled only
when the logical switcher 1 signal format is 3840×2160P
2SI or 3840×2160P SQD, and the logical switcher
2 signal format is 1080P.
The FC channels of internal format converters are set for
use as inputs (fixed).
The format converter input signal format is set to 1080P
(fixed).
The frame delay level is set to 1 frame (fixed).
The format converter conversion method can be set to
Enhancer only.
You can assign an input signal to be converted by the
format converter to an FC channel.
The following signals can be selected as inputs.
Logical switcher 2 frame memory output signals
Logical switcher 2 switcher bank output signals (re-
entry signals)
1
In the Engineering Setup >Switcher >Input menu
(7332), press [Internal FC Re-Entry Select].
The Internal FC Re-Entry Select menu (7332.11)
appears.
The status area shows the FC channel list on the left
and the list of input signals that can be assigned to FC
channels on the right.
2
In the list on the left, select the target FC channel to set.
3
In the list on the right, select an input signal.
4
Press [Set].
To set the source name of the converted input
signal
1
Select the target FC channel to set, and press [FC
Name].
2
Enter a name of up to 16 characters in the keyboard
window, and press [Enter].
To configure the enhancer
1
Select the target FC channel to set, and press
[Enhancer] in the <FC Adjust> group.
2
Set the following parameters.
a) 0 (high frequency) to 2 (low frequency)
To return the settings to the defaults
In the <FC Adjust> group, press [Default].
Notes
Parameter group [1/2]
No. Parameter Adjustment
3 Detail Gain Adjust the edge enhancement
sharpness
4 Limiter Adjust the maximum signal level to
be added to the original signal
5 Crisp Set the amplitude value for which
low-amplitude signals are not
enhanced
Parameter group [2/2]
No. Parameter Adjustment
3Level
Depend
Set the luminance range for edge
enhancement
4 Frequency Set the center frequency for edge
enhancement
a)
Parameter group [1/2]
No. Parameter Adjustment
