a) Different mix effect boards (XKS-8210/XKS-7210 or XKS-8215/
XKS-7215) cannot be installed in a single switcher at the same time.
Also, on the XVS-6000, only the XKS-7210 can be installed. The
XKS-7215 is not supported.
b) When using the XKS-8215, five M/E banks is the maximum only when all
the input/output connector boards are SDI connector boards. Four M/E
banks is the maximum when one or more network connector boards is
installed.
c) When a dedicated input is used, signals configured using the Engineering
Setup >Switcher >Input >Dedicated Input Assign menu (7332.10) can also
be selected.
Internal format
converters
Configurable only when
resource sharing enabled
Max. 16 channels
(Max. 4 channels for 4K
format)
•FC1 to FC16
configurable for input
use or output use
Max. 16 channels
(Max. 4 channels for 4K
format)
•FC1 to FC8
configurable for input
use or output use, FC9
to FC16 reserved for
output use
Max. 16 channels
(Max. 4 channels for 4K
format)
•FC1 to FC16
configurable for input
use or output use
Input/output
format
converter
• Input format converter
• Output format converter
• Input format converter
• P/I converter
• Input format converter
• P/I converter
• Input format converter
• P/I converter
GPI outputs Alarm output – – –
Keys 8 keys per switcher bank
(Max. 4 keys for 4K
format)
8 keys per switcher bank
(Max. 4 keys for 4K
format)
8 keys per switcher bank
(Max. 4 keys for 4K
format)
8 keys per switcher bank
(Max. 2 keys + 2 sub keys
for 4K format)
No restrictions on
selectable signals on sub
keys
Only primary input
(excluding XKS-T8110
input signals), black,
white, and color
background signals can
be selected on sub keys.
c)
No restrictions on
selectable signals on sub
keys
No restrictions on
selectable signals on sub
keys
Item Switcher
XVS-9000 XVS-8000 XVS-7000 XVS-6000
