Sony KLV-S40A10E Service Manual

– 15 –
WAX
RM-EA002 / RM-ED002
Specifications
Display Unit
Power Requirements:
220–240 V AC, 50 Hz
Screen Size:
KDL-S40A11E: 40 inches
KDL-S32A11E: 32 inches
KDL-S26A11E: 26 inches
KDL-S23A11E: 23 inches
Display Resolution (horizontal x vertical):
1366 dots xlines
Power Consumption:
KDL-S40A11E: 232 W
KDL-S32A11E: 127 W
KDL-S26A11E: 89 W
KDL-S23A11E: 79 W
Standby Power Consumption:
KDL-S40A11E: 0,8 W
KDL-S32A11E: 0,5 W
KDL-S26A11E: 0,5 W
KDL-S23A11E: 0,5 W
Dimensions (w × h × d):
KDL-S40A11E:
Approx. 999 x 740 x 370 mm (with stand)
Approx. 999 x 693 x 103 mm (without stand)
KDL-S32A11E:
Approx. 792 x 608 x 309 mm (with stand)
Approx. 792 x 564 x 99 mm (without stand)
KDL-S26A11E:
Approx. 658 x 517 x 309 mm (with stand)
Approx. 658 x 474 x 90 mm (without stand)
KDL-S23A11E:
Approx. 566 x 448 x 218 mm (with stand)
Approx. 566 x 411 x 89 mm (without stand)
Weight:
KDL-S40A11E:
Approx. 33 kg (with stand)
Approx. 26,5 kg (without stand)
KDL-S32A11E:
Approx. 20 kg (with stand)
Approx. 16 kg (without stand)
KDL-S26A11E:
Approx. 16,5 kg (with stand)
Approx. 12,5 kg (without stand)
KDL-S23A11E:
Approx. 13 kg (with stand)
Approx. 9,5 kg (without stand)
Panel System
LCD (Liquid Crystal Display) Panel
TV System
Analogue: Depending on your country/region selection:
B/G/H, D/K, L, I.
Digital: DVB-T.
Colour/Video System
Analogue: PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Digital: MPEG-2 MP@ML
Aerial
75 ohm external terminal for VHF/UHF
Channel Coverage
Analogue: VHF: E2–E12
UHF: E21–E69
CATV: S1–S20
HYPER: S21–S41
D/K: R1–R12, R21–R69
L: F2–F10, B–Q, F21–F69
I: UHF B21–B69
Digital: VHF/UHF
Terminals
• AV1: / 1
21-pin Scart connector (CENELEC standard) including
audio/video input, RGB input, and TV audio/video
output.
• AV2: / 2 (SMARTLINK)
21-pin Scart connector (CENELEC standard) including
audio/video input, RGB input, selectable audio/video
output, and SmartLink interface
• AV3: 3
Y:1 Vp-p, 75 ohms, 0.3V negative sync
P
B :0.7 Vp-p, 75 ohms
P
R :0.7 Vp-p, 75 ohms
Video: 480i, 576i, 480p, 576p, 720p, 1080i
3 Audio input (phono jacks)
500 mVrms
Impedance: 47 kilo ohms
• AV4: 4S video input (4-pin mini DIN)
4 Video input (phono jack)
4 Audio input (phono jacks)
• AV5: 5
PC Input (15 Dsub) (see page 36)
G: 0.7 Vp-p, 75 ohms, non Sync on Green
B: 0.7 Vp-p, 75 ohms, non Sync on Green
R: 0.7 Vp-p, 75 ohms, non Sync on Green
HD: 1-5 Vp-p
VD: 1-5 Vp-p
PC audio input: minijack.
• Audio output (Left/Right) (phono jacks)
• AV6: 6 (KDL-S40A11E, KDL-S32A11E, KDL-
S26A11E only)
HDMI: Video: 480i, 576i, 480p, 576p, 720p, 1080i
Audio: Two channel linear PCM 32, 44.1 and
48 kHz, 16, 20 and 24 bits.
AUDIO:500 mVrms (100% modulation)
Impedance: 47 kilo ohms
• i Headphones jack
•
CAM ( Conditional Access Module) slot
•MODEM
Modem jack (Not supported on this TV)
Sound Output
KDL-S40A11E: 10 W +10 W (RMS)
KDL-S32A11E: 10 W +10 W (RMS)
KDL-S26A11E: 10 W + 10 W (RMS)
KDL-S23A11E: 5 W + 5 W (RMS)
Supplied Accessories
• Remote RM-ED002 (1)
• Size AA batteries (R6 type) (2)
• Support belt (1) and screw (2)
•Mains Lead (1)
Additional Information
Optional Accessories
• Wall-Mount Bracket SU-PW2 (KDL-S40A11E)
• Wall-Mount Bracket SU-WL31 (KDL-S32A11E,
KDL-S26A11E, KDL-S23A11E)
• TV Stand SU-FF51 (KDL-S40A11E)
Design and specifications are subject to change
without notice.
PC Specifications
Signals Horizontal
(Pixel)
Vertical
(Line)
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Standard
VGA 640 480 31.5KHz 60Hz VGA
640 480 37.9KHz 72Hz VESA
640 480 37.5KHz 75Hz VESA
720 400 31.47KHz 70Hz VGA-T
SVGA 800 600 35.1KHz 56Hz
VESA Guidelines
800 600 37.9KHz 60Hz VESA Guidelines
800 600 48.1KHz 72Hz VESA
800 600 46.9KHz 75Hz VESA
XGA 1024 768 48.4KHz 60Hz
VESA Guidelines
1024 768 56.5KHz 70Hz VESA
1024 768 60.0KHz 75Hz VESA
WXGA 1280 768 47.40KHz 60Hz VESA
1280 768 47.78KHz 60Hz VESA
This TV does not support Sync on Green or Composite Sync.
If a signal other than in the above chart is input, it may not be displayed properly or may not be displayed as you set.
Using the Vertical frequency (Hz) of the personal computer at 60 is recommended.
