Sony LMD1530W User Manual

Adjustment Using the Menus
17
MARKER SELECT
CENTER MARKER
SAFETY AREA
MARKER LEVEL
REMOTE
PARALLEL REMOTE
1PIN
2PIN
3PIN
4PIN
6PIN
7PIN
8PIN
KEY INHIBIT
KEY INHIBIT
Adjusting and Changing the
Settings
STATUS menu
The STATUS menu is used to display the current status
of the unit. The following items are displayed:
For the video input
•Signal format
• Color temperature
• Gamma
• Component level
•NTSC setup
• RGB/Component select
•Scan mode
• Model name and serial number
•Option
For the DVI input
• Signal format
•fH
•fV
• Color temperature
• Model name and serial number
•Option
COLOR TEMP/BAL menu
The COLOR TEMP/BAL menu is used for adjusting the
picture white balance.
You need to use the measurement instrument to adjust
the white balance.
Recommended: Konica Minolta color analyzer CA-210
FORMAT xxxxxxxxx
xxxxxxxx
COLOR TEMP xxx
GAMMA xx
COMPONENT LEVEL xxxxx
NTSC SETUP x
RGB/COMP SEL xx
SCAN MODE xxxxxxxx
STATUS 1/2
LMD-1530W xxxxxxx
OPTION BKM-320D
STATUS 2/2
Submenu Setting
COLOR TEMP Selects the color temperature from
among HIGH, LOW and USER
setting.
FORMAT xxx
xxxxxxx
fH xxxxxxx
fV xxxxx
COLOR TEMP xxxx
STATUS 1/2
LMD-1530W xxxxxxx
OPTION BKM-320D
STATUS 2/2
COLOR TEMP: xxxxxx
MANUAL ADJUSTMENT
ADJUST GAIN:
ADJUST BIAS:
COPY FROM: xxx
COLOR TEMP/BAL
