Adjustment Using the Menus
18
USER CONTROL menu
The USER CONTROL menu is used for adjusting the
picture.
Items that cannot be adjusted depending on the input
signal are displayed in black.
For details of input signal and adjustable / setting items,
see page 9.
USER CONFIG menu
The USER CONFIG menu is used for setting the system
and marker. You can set the display language and so on.
Items that cannot be adjusted depending on the input
signal are displayed in black.
SYSTEM SETTING
MANUAL
ADJUSTMENT
If you set the COLOR TEMP to
USER setting, the item displayed is
changed from black to white, which
means you can adjust the color
temperature.
• ADJUST GAIN: Adjusts the
color balance (GAIN).
• ADJUST BIAS: Adjusts the
color balance (BIAS).
• COPY FROM: If you select
HIGH or LOW, the white
balance data for the selected
color temperature will be
copied in the USER setting.
Submenu Setting
CONTROL You can adjust the picture.
• CONTRAST: Adjusts the
picture contrast.
• BRIGHTNESS: Adjusts the
picture brightness.
• CHROMA: Adjusts color
intensity. The higher the
setting, the greater the
intensity. The lower the
setting, the lower the
intensity.
• PHASE: Adjusts color tones.
The higher the setting, the
more greenish the picture.
The lower the setting, the
more purplish the picture.
• APERTURE: Adjusts the picture
sharpness.
The higher the setting, the
sharper the picture. The
lower the setting, the softer
the picture.
• BACKLIGHT: Adjusts the
backlight. When the setting
is changed, the brightness of
the backlight is changed.
Submenu Setting
CONTROL
CONTRAST: xx
BRIGHTNESS: xx
CHROMA: xx
PHASE: xx
APERTURE: x
BACKLIGHT: x
USER CONTROL
Submenu Setting
RGB/COMP SEL When a signal input via the RGB/
COMPONENT connector is being
monitored, based on the signal
being input, select RGB or COMP
(component).
COMPONENT LEVEL Selects the component level from
among three modes.
• SMPTE: for 100/0/100/0 signal
• BETA0: for 100/0/75/0 signal
• BETA7.5: for 100/7.5/75/7.5
signal
NTSC SETUP Selects the NTSC setup level from
two modes.
The 7.5 setup level is used mainly
in North America. The 0 setup level
is used mainly in Japan.
SYSTEM SETTING:
MARKER SETTING:
USER CONFIG
RGB/COMP SEL: xxx
COMPONENT LEVEL: xxxxx
NTSC SETUP: x
SCAN: xxxxxx
GAMMA: xx
FORMAT DISPLAY: xx
LANGUAGE: ENGLISH
BACKGROUND: xx
I/P MODE: x
USER CONFIG – SYSTEM SETTING 1/2
SD PIXEL MAPPING
COMPOSITE&Y/C: xxxxxxx
RGB/COMPONENT: xxxxxxx
USER CONFIG – SYSTEM SETTING 2/2
