Adjustment Using the Menus
19
SCAN Sets the scan size of the picture.
Select from OFF and FULL.
The display format changes
depending on the mode selected.
(See “Scan mode image” on page
20)
• OFF: Changes between over scan
and normal scan.
• FULL: Changes to over scan,
normal scan or full screen.
GAMMA Select the appropriate gamma
mode. You can select from among
five settings. When "3" is selected,
the setting is roughly same as the
gamma mode of the CRT (2.2).
FORMAT DISPLAY Selects the display mode of the
signal format.
• ON: The format is always
displayed.
• OFF: The display is hidden.
• AUTO: The format is displayed
for about five seconds when
the input of the signal starts.
LANGUAGE Selects the menu or message
language from among seven
languages.
• ENGLISH: English
• FRANÇAIS: French
• DEUTSCH: German
• ESPAÑOL: Spanish
• ITALIANO: Italian
• : Japanese
•: Chinese
BACKGROUND Sets the brightness of the black bars
appearing in the upper and lower
positions of the screen, or on the
sides of the screen.
• OFF: Displays a darker bar
(black).
• ON: Displays a brighter bar
(gray).
I/P MODE (picture delay
minimum)
Select to set the delay by the picture
processing to the minimum level
when the signal is input.
• INTER-FIELD: Performs
interpolation depending on
the movement of the images
between the fields. It takes
longer than “LINE
DOUBLER” for processing
the picture. “INTER-
FIELD” is the factory
setting.
• LINE DOUBLER: The
processing time is shorter.
Performs interpolation by
repeating each line in the
data receiving sequence
regardless of the field. As
the line flicker is displayed
in this mode, it is available
for checking the line flicker
of the telop work and so on.
Submenu Setting
SD PIXEL MAPPING Selects SD picture size (pixels)
according to input signal format.
• COMPOSITE&Y/C: Set to
monitor the signal input
through the LINE connector
(VIDEO IN or Y/C IN
connector).
• RGB/COMPONENT: Set to
monitor the signal input
through the RGB/
COMPONENT connector.
When picture signals in the size
of 720 × 576 (50i) (or 720 × 487
(60i)) are input
Select 720 × 576 (or 720 ×
487). This is the default
setting.
When 702 × 576 (or 712 ×
483) is selected, all sides of
the input picture are cut off
by several pixels.
When picture signals in the size
of 702 × 576 (50i) (or 712 × 483
(60i)) or equivalent are input
Select 702 × 576 (or 712 ×
483).
When 720 × 576 (or 720 ×
487) is selected, a black
border (of several pixels
wide) appears around the
input picture.
Submenu Setting
