Sony MCS-8M Operating Instructions

II-16
Details on [Effect] Menu
Chapter 2 Video Switching
[Wipe Modify] Menu
Display the [Wipe Modify] menu by pressing the V1 knob while [Wipe Adjust] is selected.
DME Wipe
Edge
Add a border around the DME pattern
(border), and defocus the edge of an
added border (soft border).
V2 Type DME wipe edge
type
Off, Border,
S-Brdr (soft
border)
II-14
V3 Width Adjusts border
width
0.00 to 100.00
(2.00)
V4 Soft Defocus
condition for
edge
0.00 to 100.00
DME Wipe
Edge Color
Adjust the color of a DME wipe edge. V2 Lum Luminance 0.00 to 100.00
(14.63)
II-14
V3 Sat Saturation 0.00 to 100.00
(50.09)
V4 Hue Hue 359.99 to 0.00
(349.83)
DME Wipe
Bkgd Color
Adjust the background color for the DME
wipe.
V2 Lum Background
color luminance
0.00 to 100.00 II-14
V3 Sat Background
color saturation
0.00 to 100.00
V4 Hue Background
color hue
359.99 to 0.00
Menu item Description Knob Parameter Meaning Setting range Reference
page
Menu item Description Knob Parameter Meaning Setting range Reference
page
Positioner Turn the positioner for adjusting the wipe
position on/off.
If you also select [On] with the V3 knob,
the pattern will move from the location to
which the pattern was moved with the
positioner to the center of the screen as a
result of the transition.
Tip
The patterns for which the positioner can
be used are as follows.
17, 18, 21, 22, 23, and 24
V3 AutoCT Turns auto
center function
on/off
Off, On II-11
V4 Pos Turns positioner
on/off
Off, On
Positioner
Adjust
Adjust the wipe position.
If you want to reset the setting value to
“0.00,” press the V4 knob.
V2 Pos H Adjusts position
in horizontal
direction
–200.00 to
+200.00 (0.00) (A
negative value
moves the pattern
left, and a positive
value moves it
right)
II-11
V3 Pos V Adjusts position
in vertical
direction
–200.00 to
+200.00 (0.00) (A
negative value
moves the pattern
down, and a
positive value
moves it up)
V4 Center Resets setting
value to “0”
–
