II-38
Importing and Exporting Configuration Data
Chapter
Chapter 5 Importing and Exporting Files
Importing and Exporting
Files
Importing and Exporting
Configuration Data
You can export configuration data in which various
settings of the unit have been saved to a USB flash drive,
and import saved configuration data to the unit.
Configuration data contains various settings of the unit.
When you want to, for example, restore previous settings,
you can easily make the settings by importing the
configuration data. We recommend that you save the
configuration data such as when you change the settings.
Exporting Configuration Data
1
Insert the USB flash drive into the USB connector of
the unit.
2
Press the FILE button in the menu control block to
display the [File] menu, turn the V1 knob to select
[Export Config], and press the V4 knob to start
exporting.
The folder to which the files are exported is as shown
below.
Folder name:
\Sony\MCS\CONFIG\YYMMDD-HHMMSS
The following settings are not saved under configuration
data.
Front panel buttons
• ACCESS/PFL (1 to 6)
•DIM
•MONITOR SEL
• CH ON (1 to 6)
• Bus delegation buttons (BKGD, KEY, AUX 1, AUX 2)
• Menu selection buttons
• Numeric keypad buttons (EFF, SNAPSHOT, DIRECT/
ESC)
Menus
Miscellaneous
• Frame memory video
• Make sure that the number of files in the folder does not
exceed 99. Even if a folder contains 100 files or more,
only 99 files will be displayed in the list. To delete a file,
select the file you want to delete and hold down the V1
knob.
Tip
Tip
Note
Menu Group Parameter
Frame Memory Input Freeze Input, Freeze
Select FM
Export Source, Num
Frame Memory > Freeze All –
Frame Memory > Import All –
Misc Port Enable GPI, RS232C
File All –
File > Import Config All –
File > Import Snapshot All –
Setup > System Startup Mode All
Date All
Time All
To Next Page
