MEX-BT3600U
17
3-7. CHASSIS (T) SUB ASSY
3-8. ROLLER ARM ASSY
chassis (T) sub ass
y
claw
two precision
screws
(P1.7
×
2.2)
two precision
screws
(P1.7
×
2.2)
Remove the chassis (T) sub assy
in the direction of arrow.
Remove the three solders.
washer
gear (RA1)
roller arm assy
spring (RAL)
spring (RAR)
