VIDEO Status Screen / BUTTON/REMOTE Status Screen
116
Status Displays
The information on video formats and settings for
the COMPONENT OUT, SDI OUT, HDMI
OUT, A/V OUT and i.LINK connectors is
displayed.
Video Format: Video format setting
The video format set in “Video Format” of the
OTHERS menu is displayed.
In HD Mode, the horizontal resolution, frame
rate, and scan format are displayed.
In SD Mode, the frame rate, scan format, and
aspect (SQ/EC) are displayed.
Rec Mode: Recording bit rate (HD Mode only)
The bit rate (HQ or SP) of the video format set in
“Video Format” of the OTHERS menu is
displayed.
Output Select: Component and digital output
status
The video format of the signal being fed from the
COMPONENT OUT, SDI OUT, and HDMI
OUT connectors according to the “Output Select”
setting of the VIDEO SET menu is displayed.
Video Out: Output status of the A/V OUT
connector
The format (NTSC or PAL) of the analog
composite signal being fed from the A/V OUT
connector is displayed when “Output Select” of
the VIDEO SET menu is set to “Composite.”
When the “Output Select” setting is other than
“Composite,” “Off” is displayed.
Down Converter: Down-converter setting of the
SD output (HD Mode only)
The “Down Converter” setting (Squeeze, Edge
Crop, Letterbox) of the VIDEO SET menu is
displayed.
i.LINK I/O: i.LINK I/O status
The i.LINK I/O setting (HDV/DVCAM/Disable)
of the OTHERS menu is displayed.
The functions assigned to the assignable buttons
and the status of the IR Remote Commander are
displayed.
Assign Button: Assignable button statuses
The functions assigned with the “Assign Button”
of the OTHERS menu to the respective
assignable buttons are displayed.
IR Remote: IR Remote Commander status
The status (On: enabled, Off: disabled) of the IR
Remote Commander is displayed
VIDEO Status Screen
Video For m at
Rec
M ode
O utput S elect
A/V
O ut
D o w n C onver t er
i. L I NK I/ O
: 1920/60i
:
HQ
: 1920/60i
:
O ff
:
Squeeze
:
Disable
VIDEO 3 / 5
BUTTON/REMOTE Status
Screen
Assign But ton 1: Freeze M ix
2: O ff
3: O ff
4: Rec Review
IR
Re m ote : O n
BUTTON / RE
M OTE 4 / 5

Sony PMW-EX1R Specifications

General

Sensor type	CMOS
Total megapixels	- MP
Filter size	77 mm
Digital zoom	- x
Optical zoom	14 x
Image stabilizer	Yes
Focal length range	5.8 - 81.2 mm
Focal length (35mm film equivalent)	31.4 - 439 mm
Camcorder media type	HDD, Memory card
Internal storage capacity	32 GB
Focus adjustment	Auto/Manual
Camera shutter speed	1/32 - 1/2000 s
Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display resolution (numeric)	921000 pixels
Viewfinder screen size	0.45 \
Product color	Black
Minimum illumination	0.14 lx
Video formats supported	MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
PCM digital audio	16-bit/48 kHz
USB connector type	Mini-USB B
USB 2.0 ports quantity	1
Battery life (max)	3 h
Video recording time	1.6 h
Operating temperature (T-T)	0 - 40 °C
Cables included	USB
Power requirements	12 V DC

Weight and Dimensions

Depth	199 mm
Width	179 mm
Height	308 mm
Weight	2400 g
