Sony PMW-EX1R User Manual

Table of Contents
6
Overview
Package Configuration ........................................................... 12
Features .................................................................................... 13
Using the Software .................................................................. 16
Reading the CD-ROM Manuals ............................................ 16
Parts Identifications ................................................................ 17
Camcorder .................................................................... 17
IR Remote Commander (Supplied) .............................. 21
On-Screen Indications ............................................................ 22
Indications in Camera Mode ........................................ 22
Direct Menu Operation ................................................ 23
Preparations
Power Supply ........................................................................... 25
Using a Battery Pack .................................................... 25
Using AC Power (DC IN Power) ................................. 26
Turning Power On ........................................................ 27
Turning Power Off ....................................................... 27
Setting the Clock ..................................................................... 28
Adjusting the LCD Monitor and Viewfinder ....................... 29
Adjusting the LCD Monitor ......................................... 29
Adjusting the Viewfinder ............................................. 30
Adjusting the Grip .................................................................. 31
Using the IR Remote Commander ........................................ 32
Handling SxS Memory Cards ................................................ 33
About SxS Memory Cards ........................................... 33
Inserting/Removing an SxS Memory Card .................. 34
Switching Between SxS Memory Cards ...................... 35
Formatting an SxS Memory Card ................................ 35
Checking the Remaining Time Available for
Recording ............................................................... 36
Restoring an SxS Memory Card .................................. 36
Using an External Hard Disk ................................................. 37
Attaching/Removing the PHU-120R ........................... 37
Formatting the PHU-120R ........................................... 38
Table of Contents

Sony PMW-EX1R Specifications

General

Sensor type	CMOS
Total megapixels	- MP
Filter size	77 mm
Digital zoom	- x
Optical zoom	14 x
Image stabilizer	Yes
Focal length range	5.8 - 81.2 mm
Focal length (35mm film equivalent)	31.4 - 439 mm
Camcorder media type	HDD, Memory card
Internal storage capacity	32 GB
Focus adjustment	Auto/Manual
Camera shutter speed	1/32 - 1/2000 s
Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display resolution (numeric)	921000 pixels
Viewfinder screen size	0.45 \
Product color	Black
Minimum illumination	0.14 lx
Video formats supported	MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
PCM digital audio	16-bit/48 kHz
USB connector type	Mini-USB B
USB 2.0 ports quantity	1
Battery life (max)	3 h
Video recording time	1.6 h
Operating temperature (T-T)	0 - 40 °C
Cables included	USB
Power requirements	12 V DC

Weight and Dimensions

Depth	199 mm
Width	179 mm
Height	308 mm
Weight	2400 g
