Sony PMW-EX1R User Manual

Setup Menu List
127
Menu Configuration and Detailed Settings
AUDIO SET Menu
AUDIO SET
Menu items Subitems and setting values Contents
Audio Input
Setting for audio
inputs
[M]
TRIM CH-1
–20 dBu to –65 dBu (–41 dBu)
Finely adjust the sensitivity of channel 1 of external
microphone input in steps of 3 dB in Manual audio
adjustment mode.
TRIM CH-2
–20 dBu to –65 dBu (–41 dBu)
Finely adjust the sensitivity of channel 2 of external
microphone input in steps of 3 dB in Manual audio
adjustment mode.
INT MIC Level
–12 dB / –6 dB / –0 dB / +6 dB
/ +12 dB
Select the built-in microphone level in Manual audio
adjustment mode.
Limiter
On / Off
Turn the audio limiter on/off.
MIC AGC
High / Low
Select the sensitivity of the microphone inputs.
AGC Link
Linked / Separated
Select the gain link condition when the audio level adjustment
is in AGC mode.
Linked: To vary the CH-1 gain and the CH-2 gain in
synchronization.
Separated: To vary the CH-1 gain and the CH-2 gain
independently according to the respective levels.
1KHz Tone
On / Off
Turn the 1-kHz reference tone signal on/off.
Wind Filter CH-1
On / Off
Turn the wind filter for channel 1 on/off.
Wind Filter CH-2
On / Off
Turn the wind filter for channel 2 on/off.
EXT CH Select
CH-1
CH-1/CH-2
CH-1: To record channel 1 audio input on both channels 1
and 2.
It is recommended to set the AUDIO SELECT (AUTO/
MANUAL) switch and AUDIO LEVEL control for CH-2
(page 64) as well as the above TRIM CH-2 to the same
conditions as those for CH-1.
CH-1/CH-2: To record channel 1 and channel 2 inputs on the
respective channels.
Audio Output
Setting for audio
outputs
Monitor CH
CH-1/CH-2 (CH-3/CH-4)
CH-1+CH-2 (CH-3+CH-4)
CH-1 (CH-3)
CH-2 (CH-4)
Select the audio channel(s) to be fed to the headphones and
the built-in speaker.
CH-1/CH-2 (CH-3/CH-4): Stereo
CH-1+CH-2 (CH-3+CH-4): Mix
CH-1 (CH-3): CH-1 (CH-3) only
CH-2 (CH-4): CH-2 (CH-4) only
( ): with Output CH set to “CH-3/CH-4”
Output CH
CH-1/CH-2
CH-3/CH-4
Select audio output channels from either channels 1 and 2 or
channels 3 and 4.
Alarm Level
0 to 7 (4)
Set the alarm sound volume.
Beep
On / Off
Select whether or not to sound a beep upon each operation.

Sony PMW-EX1R Specifications

General

Sensor type	CMOS
Total megapixels	- MP
Filter size	77 mm
Digital zoom	- x
Optical zoom	14 x
Image stabilizer	Yes
Focal length range	5.8 - 81.2 mm
Focal length (35mm film equivalent)	31.4 - 439 mm
Camcorder media type	HDD, Memory card
Internal storage capacity	32 GB
Focus adjustment	Auto/Manual
Camera shutter speed	1/32 - 1/2000 s
Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display resolution (numeric)	921000 pixels
Viewfinder screen size	0.45 \
Product color	Black
Minimum illumination	0.14 lx
Video formats supported	MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
PCM digital audio	16-bit/48 kHz
USB connector type	Mini-USB B
USB 2.0 ports quantity	1
Battery life (max)	3 h
Video recording time	1.6 h
Operating temperature (T-T)	0 - 40 °C
Cables included	USB
Power requirements	12 V DC

Weight and Dimensions

Depth	199 mm
Width	179 mm
Height	308 mm
Weight	2400 g
