Sony PMW-EX1R User Manual

Connecting an External Device (i.LINK Connection)
145
Connecting External Devices
Note
DVCAM streams cannot be recorded.
1 Set the external signal to a format that
can be recorded on the camcorder.
Signals of 1440 × 1080/59.94i can be
recorded when “Video Format” (page 136) is
set to SP 1440/60i or SP 1440/24P. Signals of
1440 × 1080/50i can be recorded when set to
SP 1440/50i.
Recording is not allowed with other
combinations of “Video Format” and input
signals.
2 Set “i.LINK I/O” (page 135) of the
OTHERS menu to “HDV.”
3 Set the camcorder to Media mode.
4 Press the STOP button to set the
camcorder to STOP mode.
The input image is displayed on the LCD
monitor/EVF screen and the monitor
connected via the COMPONENT OUT
connector or A/V OUT connector.
The audio signal is output from the built-in
speaker (or headphones connected to the
headphone jack) and the speaker of the
monitor connected to the A/V OUT
connector.
5 Press the REC START/STOP button on
the handle.
Recording begins.
Notes
• The REC START/STOP button on the grip does
not function.
• An error is generated in the following cases. In
such a case, cancel Recording mode by pressing
the REC START/STOP button.
—The video format of input signal does not
match that specified on the camcorder.
—A copy-protected stream is being fed in.
• If the input to the camcorder becomes no signal
during recording, the tally lamps and the
i.LINK zREC status indication on the LCD
monitor/EVF screen flash, indicating that no
signal is being recorded on the SxS memory
card.
When an input signal is resumed, recording is
restarted, incrementing the clip number on the
memory card.

Sony PMW-EX1R Specifications

General

Sensor type	CMOS
Total megapixels	- MP
Filter size	77 mm
Digital zoom	- x
Optical zoom	14 x
Image stabilizer	Yes
Focal length range	5.8 - 81.2 mm
Focal length (35mm film equivalent)	31.4 - 439 mm
Camcorder media type	HDD, Memory card
Internal storage capacity	32 GB
Focus adjustment	Auto/Manual
Camera shutter speed	1/32 - 1/2000 s
Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display resolution (numeric)	921000 pixels
Viewfinder screen size	0.45 \
Product color	Black
Minimum illumination	0.14 lx
Video formats supported	MPEG2
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
PCM digital audio	16-bit/48 kHz
USB connector type	Mini-USB B
USB 2.0 ports quantity	1
Battery life (max)	3 h
Video recording time	1.6 h
Operating temperature (T-T)	0 - 40 °C
Cables included	USB
Power requirements	12 V DC

Weight and Dimensions

Depth	199 mm
Width	179 mm
Height	308 mm
Weight	2400 g
