Administrating the Camera
Setting the Camera Image and Audio — Video / Audio Menu Setting the Camera Image — Video Menu
34
Note
Perform the following before setting the privacy
masking.
•Set Image size1 in the Video codec tab of the Video /
Audio menu or Video menu to the maximum rate.
• Deselect the checkbox of Image 1 in the PTZ control
tab of the PTZ control menu.
• Deselect the checkbox of Stabilizer in the Installation
tab of the System menu. After setting the privacy
masking, set the Stabilizer function again.
Preview screen
This screen is for monitoring images and configuring
privacy masking.
You can move the position of the privacy mask displayed
on the preview screen by drag and drop.
Effect
Set the effect of privacy masks.
Color
Specify the color of privacy masks. This setting is
common to every privacy mask.
Position
Select the number corresponding to the display position
on the preview screen.
After completing the configuration, register by clicking
OK.
Clear
Click the button to delete the privacy mask set in
Position.
Clear all
Click the button to delete all privacy mask.
Setting a privacy mask
Operate according to the following procedure to set a
privacy mask in the position of your choice:
1
Select the number to register from the Position
drop-down list.
2
Specify the privacy mask area by dragging the
mouse on the preview screen.
3
Select the effect and color of the mask from the
Effect and Color drop-down list.
Note
The color is common to every privacy mask. The
color selected last is applied.
4
Click OK.
The mask is displayed on the preview screen.
OK/Cancel
See “Buttons common to every menu” on page 22.
Streaming Tab
Use this tab to set the items for the transmission by
unicast or multicast.
Unicast streaming
Specify the transmission port numbers of the H.264
video data and audio data to be used when Unicast is
selected from the Connection drop-down list in the
Other panel on the live viewer.
Video port number 1, 2, 3
Specify the transmission port number of the H.264 video
data. The default setting is 50000, 52000 or 54000.
Specify an even number from 1024 to 65534. Two port
numbers (the number specified here and an odd number
with 1 added to the specified number) are actually used
for video data communication and control. When
