Administrating the Camera
Setting the Action output — Action output Menu
61
Setting the Action
output
— Action output
Menu
When you click in the Administrator
menu, the Action output menu appears.
The Action output Menu consists of the following tabs:
SNC-VB635/VB630/VB600/VB600B/VM630/
VM600/VM600B/VM631/VM601/VM601B/
VM632R/VM602R: Execution Condition, Mail
Transfer, Edge Storage, Alarm output, Voi ce
alert, HTTP alarm notification and FTP still
image sending.
SNC-EB630/EB630B/EB600/EB600B/EB632R/
EB602R/EM630/EM600/EM631/EM601/
EM632R/EM602R: Execution Condition, Mail
Transfer, HTTP alarm notification and FTP still
image sending.
SNC-XM637/XM636/XM632: Execution Condition,
Mail Transfer, Edge Storage, HTTP alarm
notification and FTP still image sending.
SNC-XM631: Execution Condition, Mail Transfer,
Alarm output, Edge Storage, HTTP alarm
notification and FTP still image sending.
SNC-CX600W/CX600: Execution Condition, Mail
Transfer, Edge Storage, Voice alert, White LED,
HTTP alarm notification and FTP still image
sending.
SNC-VB632D: Execution Condition, Mail Transfer,
Alarm output, Edge Storage, Voice alert, White
LED, HTTP alarm notification and FTP still
image sending.
Execution Condition Tab
Set execute conditions for each action.
Set the action output execute conditions when the
condition created in the Event condition tab is
implemented.
Displayed items vary depending on the function.
Mail Transfer: Set the condition of mail transfer.
Alarm output 1: Set the condition to control alarm
output of the I/O port on the rear of the camera.
Alarm output 2: Set the condition to control alarm
output of the I/O port on the rear of the camera.
Edge Storage movie: Set the condition to record
movies using the Edge Storage function.
Edge Storage still image: Set the condition to record
still images using the Edge Storage function.
Voice alert 1: Set the condition of Voice alert 1 recorded
in the camera.
Voice alert 2: Set the condition of Voice alert 2 recorded
in the camera.
Voice alert 3: Set the condition of Voice alert 3 recorded
in the camera.
HTTP alarm notification 1: Set the condition for the
HTTP alarm notification to recipient 1.
HTTP alarm notification 2: Set the condition for the
HTTP alarm notification to recipient 2.
HTTP alarm notification 3: Set the condition for the
HTTP alarm notification to recipient 3.
FTP still image sending: Set the condition for sending
with the FTP still image sending function.
White LED: Set the White LED lighting condition.
Only the Presence Sensor (SNC-CX600W/CX600)
and the Motion detection (SNC-VB632D) can be
selected. The White LED lights up when it is dark.
Mail Transfer Tab — Setting the
e-Mail (SMTP) Function
SMTP Server
Notes
• You cannot send an audio file by using the e-mail
sending function.
• The frame rate and operability on the viewer may be
reduced while a file is being transmitted by the e-Mail
(SMTP) function.
Action output
