Sony SRG-X400 Command List

17
Command List (4/8)
Number in ( ) is MENU display values.
*
Only available for BRC-X400/X401.
Command Set Command Command Packet Comments
DETAIL LEVEL Reset 8x 01 04 02 00 FF To return to 7 value
Up 8x 01 04 02 02 FF
Down 8x 01 04 02 03 FF
Direct 8x 01 04 42 00 00 0p 0p
FF
pp: 00 - 0F
MODE Direct 8x 01 05 42 01 0p FF p: 0=Auto, 1=Manual
BANDWIDTH Direct 8x 01 05 42 02 0p FF p: 0 - 4
CRISPENING Direct 8x 01 05 42 03 0p FF p: 0 - 7
HV BALANCE Direct 8x 01 05 42 04 0p FF p: 5 - 9
BW BALANCE Direct 8x 01 05 42 05 0p FF p: 0 - 4
LIMIT Direct 8x 01 05 42 06 0p FF p: 0 - 7
HIGHLIGHT
DETAIL
Direct 8x 01 05 42 07 0p FF p: 0 - 4
SUPER LOW Direct 8x 01 05 42 08 0p FF p: 0 - 7
KNEE
*
KNEE SETTING On/Off 8x 01 7E 01 6D 0p FF p: 2=On, 3=Off
KNEE MODE - 8x 01 7E 01 54 0p FF p: 0=Auto, 4=Manual
KNEE SLOPE Direct 8x 01 7E 01 6F 0p 0p FF pp: 00 - 0E
KNEE POINT Direct 8x 01 7E 01 6E 0p 0p FF pp: 00 - 0C
GAMMA
*
SELECT - 8x 01 04 5B 0p FF p: 0=STD, 1=STRAIGHT, 2=PATTERN,
8=MOVIE, 9=STILL, A=CINE1, B=CINE2,
C=CINE3, D=CINE4, E=ITU709
PATTERN Direct 8x 01 05 5B 0p 0p 0p FF ppp: 001 - 200
OFFSET Direct 8x 01 04 1E 00 00 00 0p
0q 0q FF
p: Offset polarity 0 (+), 1 (–)
qq: Offset width 00 - 40
LEVEL Direct 8x 01 7E 01 71 0p 0p FF pp: 00 - 0E
BLACK GAMMA
LEVEL
Direct 8x 01 7E 01 72 0p 0p FF pp: 00 - 0E
BLACK GAMMA
RANGE
Direct 8x 01 05 5C 0p FF p: Correction range 0 (Low), 1 (Mid), 2 (High)
BLACK LEVEL Reset 8x 01 7E 04 15 00 FF To return to 30 (48) value
Up 8x 01 7E 04 15 02 FF
Down 8x 01 7E 04 15 03 FF
Direct 8x 01 7E 04 45 0p 0p FF pp: 00 - 60
PROFILE
*
- - 8x 01 7E 04 5F 0p FF p: 0=PP1, 1=PP2, 2=PP3, 3=PP4, 4=PP5,
5=PP6
FLICKER
CANCEL
- - 8x 01 04 32 0p FF p: 2=On, 3=Off
STABILIZER
- - 8x 01 04 34 0p FF p: 2=On, 3=Off
DEFOG - - 8x 01 04 37 0p 0q FF p: 2=On, 3=Off
q: Defog Level 0 (same as 2), 1 (Weak) -
3 (Strong)

Sony SRG-X400 Specifications

General

Type	IP security camera
PTZ modes	Digital PTZ
PTZ control	Yes
Placement supported	-
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling/Pole
Product color	White
LED indicators	LAN, Power
Pan range	-170 - 170 °
Pan speed	300 °/sec
White balance	Auto, Indoor, Manual, One push, Outdoor
Tilt angle range	-20 - 90 °
Camera shutter speed	1/1 - 1/10000 s
Minimum illumination	1.6 lx
Sensor type	Exmor
Number of sensors	1
Optical sensor size	1/2.5 \
Focus	Motorized/Manual
Digital zoom	40 x
Focal length range	4.4 - 88 mm
Maximum aperture number	3.8
Minimum aperture number	2
Closest focusing distance	0.08 m
LED type	IR
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels	8.5 MP
Gain control type	Auto/Manual
Maximum resolution	3840 x 2160 pixels
Supported video modes	720p, 1080i, 1080p, 2160p
Video compression formats	H.264, H.265
Supported graphics resolutions	640 x 360, 720 x 480, 720 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160
Voice codecs	AAC
Audio output channels	2 channels
Streaming method	Multicast
Supported network protocols	IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, UPnP, VISCA over IP
DC output voltage	12
Power source type	DC, PoE
Power consumption (typical)	25.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	200.2 mm
Width	158.4 mm
Height	177.5 mm
Weight	1800 g
