Sony SRG-X400 Command List

39
Lens control
*1
The range for SRG-X120/HD1M2 is 0000-4000.
Video output method (video format)
* For BRC-X400/X401 only, or only when the 4K option is applied
Pan/Tilt Status Code
( – : optional)
Zoom Position
*1
0000 - 4000 - 7AC0
Wide end Optical Digital
Tele end Tele end
Focus Position 1000 - F000
Far end Near end
Focus Near Limit 1000: Inf
Use the distance
shown as a guide
value as it may
vary depending on
the temperature
characteristics.
* The lower 1 byte
is fixed at 00.
2000: 5 m
3000: 3 m
4000: 2 m
5000: 1.5 m
6000: 1.2 m
7000: 1.0 m
8000: 0.8 m
9000: 0.6 m
A000: 47 cm
B000: 35 cm
(initial value)
C000: 26 cm
D000: 17 cm
E000: 10 cm
F000: 8 cm
Parameter Video output method
(video format)
00 1280×720/59.94p
(HDMI: 640×480/59.94p, RGB fixed)
01 1280×720/59.94p
02 1920×1080/29.97p
03 1920×1080/59.94i
04 1920×1080/59.94p (SDI Level A)
05 1920×1080/59.94p (SDI Level B)
06 3840×2160/29.97p*
11 1280×720/50p
12 1920×1080/25p
13 1920×1080/50i
14 1920×1080/50p (SDI Level A)
15 1920×1080/50p (SDI Level B)
16 3840×2160/25p*
21 1920×1080/23.98p
22 3840×2160/23.98p*
pppp Status
–––– –––– 0––– –––1 Panning reaches the end of the left.
–––– –––– 0––– ––1– Panning reaches the end of the right.
–––– –––– 0––– –1–– Tilting reaches the upper limit.
–––– –––– 0––– 1––– Tilting reaches the lower limit.
–––– –––– ––00 –––– Pan functions normally.
–––– –––– ––01 –––– Pan mechanism is defective.
–––– ––00 0––– –––– Tilt functions normally.
–––– ––01 0––– –––– Tilt mechanism is defective.
–––– 00–– 0––– –––– No movement instruction
–––– 01 –– 0––– –––– Pan/Tilt operating
–––– 1 0–– 0––– –––– Pan/Tilt operations complete.
–––– 1 1–– 0––– –––– Pan/Tilt operating failed.
––00 –––– 0––– –––– Not initialized
––01 –––– 0––– –––– Initializing
––10 –––– 0––– –––– Initialization completes.
––11 –––– 0––– –––– Initialization failed.

Sony SRG-X400 Specifications

General

Type	IP security camera
PTZ modes	Digital PTZ
PTZ control	Yes
Placement supported	-
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling/Pole
Product color	White
LED indicators	LAN, Power
Pan range	-170 - 170 °
Pan speed	300 °/sec
White balance	Auto, Indoor, Manual, One push, Outdoor
Tilt angle range	-20 - 90 °
Camera shutter speed	1/1 - 1/10000 s
Minimum illumination	1.6 lx
Sensor type	Exmor
Number of sensors	1
Optical sensor size	1/2.5 \
Focus	Motorized/Manual
Digital zoom	40 x
Focal length range	4.4 - 88 mm
Maximum aperture number	3.8
Minimum aperture number	2
Closest focusing distance	0.08 m
LED type	IR
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels	8.5 MP
Gain control type	Auto/Manual
Maximum resolution	3840 x 2160 pixels
Supported video modes	720p, 1080i, 1080p, 2160p
Video compression formats	H.264, H.265
Supported graphics resolutions	640 x 360, 720 x 480, 720 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160
Voice codecs	AAC
Audio output channels	2 channels
Streaming method	Multicast
Supported network protocols	IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, UPnP, VISCA over IP
DC output voltage	12
Power source type	DC, PoE
Power consumption (typical)	25.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	200.2 mm
Width	158.4 mm
Height	177.5 mm
Weight	1800 g
