Sony SRG-X400 Command List

6
The ACK message is not returned for these
commands and inquiries, and only the
completion message of socket number 0 is
returned.
Command execution cancel
To cancel a command which has already been
sent, send a Cancel command as the next
command. To cancel one of two commands
which have been sent, use the cancel message.
Error message “Command Canceled” will be
returned for this command, but this is not a fault.
It indicates that the command has been
cancelled.
Note
To cancel a command when VISCA PAN-TILT Drive
(page 20) is being executed, wait at least 200
msec after executing. Then send a cancel
command to ensure that PAN-TILT Drive stops
effectively.
To execute a PAN-TILT Drive command again,
wait at least 200 msec after the message
“Command Canceled” has appeared.
VISCA Device Setting Command
Before starting control of the unit, make sure to
send the Address Set command and IF_Clear
command using the broadcast.
For VISCA network administration
• Address Set*
Sets an address of a peripheral device. Use
when initializing the network, and receiving the
following network change message.
* Not available for VISCA over IP.
• Network Change*
Sent from the peripheral device to the
controller when a device is removed from or
added to the network. The address must be re-
set when this message is received.
* Not available for VISCA over IP.
VISCA interface command
• IF_Clear
Clears the command buffer in the unit. When
cleared, the operation currently being
executed is not guaranteed.
* Not available for VISCA over IP.
VISCA interface and inquiry
• CAM_VersionInq
Returns information on the VISCA interface.
Cancel Packet
Cancel 8X 2Z FF
X = 1 to 7: Address of the unit (Locked to “X = 1” for VISCA over
IP)
Z = socket number
Packet
Address Set 88 30 01 FF
Network Change Y0 38 FF
Y = 9 to F: Address of the unit + 8
Command
Packet
Reply Packet
IF_Clear 8X 01 00 01 FF Y0 50 FF
IF_Clear (broadcast)
*
88 01 00 01 FF 88 01 00 01 FF
X = 1 to 7: Address of the unit (Locked to “X = 1” for VISCA over
IP)
Y = 9 to F: Address of the unit +8 (Locked to “Y = 9” for VISCA
over IP)
Inquiry Packet Reply Packet
CAM_VersionInq 8X 09 00 02 FF Y0 50 GG GG HH HH JJ JJ KK FF
X = 1 to 7: Address of the unit (Locked to “X = 1” for VISCA over IP)
Y = 9 to F: Address of the unit +8 (Locked to “Y = 9” for VISCA over IP)
GGGG = Vender ID
0001: Sony
HHHH = Model ID
051C:BRC-X400
051D:BRC-X401
0617:SRG-X400
061C:SRG-X402
0618:SRG-X120
061A:SRG-201M2
061B:SRG-HD1M2
JJJJ = ROM revision
KK = Maximum socket # (02)

Sony SRG-X400 Specifications

General

Type	IP security camera
PTZ modes	Digital PTZ
PTZ control	Yes
Placement supported	-
Connectivity technology	Wired
Form factor	Dome
Mounting type	Ceiling/Pole
Product color	White
LED indicators	LAN, Power
Pan range	-170 - 170 °
Pan speed	300 °/sec
White balance	Auto, Indoor, Manual, One push, Outdoor
Tilt angle range	-20 - 90 °
Camera shutter speed	1/1 - 1/10000 s
Minimum illumination	1.6 lx
Sensor type	Exmor
Number of sensors	1
Optical sensor size	1/2.5 \
Focus	Motorized/Manual
Digital zoom	40 x
Focal length range	4.4 - 88 mm
Maximum aperture number	3.8
Minimum aperture number	2
Closest focusing distance	0.08 m
LED type	IR
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels	8.5 MP
Gain control type	Auto/Manual
Maximum resolution	3840 x 2160 pixels
Supported video modes	720p, 1080i, 1080p, 2160p
Video compression formats	H.264, H.265
Supported graphics resolutions	640 x 360, 720 x 480, 720 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160
Voice codecs	AAC
Audio output channels	2 channels
Streaming method	Multicast
Supported network protocols	IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, UPnP, VISCA over IP
DC output voltage	12
Power source type	DC, PoE
Power consumption (typical)	25.5 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	200.2 mm
Width	158.4 mm
Height	177.5 mm
Weight	1800 g
