Additional Information
Specifications
AUDIO POWER
SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
With 8 ohms loads, both channels driven, from
20 Hz – 20,000 Hz; rated 100 watts per
channel minimum RMS power, with no more
than 0.09% total harmonic distortion from 250
milliwatts to rated output.
Amplifier section
Power Output
Rated Power Output at Stereo Mode
1)
(8 ohms 20 Hz – 20 kHz, THD 0.09%):
100 W + 100 W
Reference Power Output at Stereo Mode
(4 ohms 20 Hz – 20 kHz, THD 0.15%):
85 W + 85 W
Reference Power Output (8 ohms 1 kHz, THD
0.7%)
FRONT
2)
: 110 W + 110 W
CENTER
2)
: 110 W
SURROUND
2)
: 110 W + 110 W
SURROUND BACK
2)
:
110 W + 110 W
Reference Power Output (4 ohms 1 kHz, THD
0.7%)
FRONT
2)
: 100 W + 100 W
CENTER
2)
: 100 W
SURROUND
2)
: 100 W + 100 W
SURROUND BACK
2)
:
100 W + 100 W
1)
Depending on the sound field settings and the
source, there may be no sound output.
2)
Measured under the following conditions:
Power requirements: 120 V AC, 60 Hz
Frequency response
PHONO RIAA equalization curve
±0.5 dB
Analog 10 Hz – 100 kHz,
±3 dB (with sound field
and equalizer bypassed)
Input
PHONO Sensitivity: 2.5 mV
Impedance: 50 kohms
S/N
3)
: 90 dB
(A, 20 kHz LPF)
4)
Analog Sensitivity: 150 mV/
50 kohms
S/N
3)
: 100 dB
(A, 20 kHz LPF)
4)
Digital (Coaxial) Impedance: 75 ohms
S/N: 96 dB
(A, 20 kHz LPF)
4)
Digital (Optical) S/N: 96 dB
(A, 20 kHz LPF)
4)
Output (analog)
AUDIO OUT Voltage: 150 mV/
1 kohm
SUBWOOFER Voltage: 2 V/1 kohm
Equalizer
Gain levels ±10 dB, 1 dB step
3)
INPUT SHORT (with sound field and equalizer
bypassed).
4)
Weighted network.
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
With 10-kHz tuning scale
530 – 1,710 kHz
5)
With 9-kHz tuning scale
531 – 1,710 kHz
5)
Antenna (aerial) Loop antenna (aerial)
Intermediate frequency
450 kHz
5)
You can change the AM tuning scale to either 9
kHz or 10 kHz. After tuning in any AM station,
turn off the receiver. While holding down
TUNING MODE, press POWER on the receiver.
All preset stations will be erased when you change
the tuning scale. To reset the scale to 10 kHz (or 9
kHz), repeat the procedure.
continued

Sony STR-DA3400ES Specifications

General

Equalizer	Yes
Product color	Silver
Frequency range	20 - 20000 Hz
RMS rated power	700 W
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.09 %
Supported radio bands	AM, FM
I/O ports	1 x AV 1 x DM-Port 4 x Audio In 1 x Audio Out 5 x A/V In 1 x A/V Out 1 x S-Video 3 x Component Video In 1 x Component Video Out 1 x Multi-ch In 1 x SW 4 x HDMI In 1 x HDMI Out 4 x Opt. IN 1 x Opt. Out 3 x Coax.
Connectivity technology	Wired
Dimensions (WxDxH)	430 x 388 x 157.5 mm
Power requirements	230 V, 50/60 Hz
HDMI ports quantity	5
Package weight	16000 g
Power consumption (standby)	0.7 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	12500 g
