Advanced Speakers Set Up
x Test Tone (Test Tone)
•OFF
•AUTO
The test tone is output from each speaker in
sequence.
• L, C, R, SR, SB, SBR, SBL, SL, SW
You can select which speakers will output
the test tone.
Some items may not be displayed,
depending on the setting of the speaker
pattern.
x Phase Noise (Phase Noise)
•OFF
• L/C, C/R, L/R, R/SL, R/SR, SR/SL, SR/
SBR, SBR/SBL, SR/SB, SBL/SL, SB/SL,
SL/L, L/SR
Lets you output the test tone sequentially
from adjacent speakers.
Some items may not be displayed,
depending on the setting of the speaker
pattern.
x Phase Audio (Phase Audio)
•OFF
• L/C, C/R, L/R, R/SL, R/SR, SR/SL, SR/
SBR, SBR/SBL, SR/SB, SBL/SL, SB/SL,
SL/L, L/SR
Lets you output the front 2 channel source
sound (instead of the test tone) sequentially
from adjacent speakers.
Some items may not be displayed,
depending on the setting of the speaker
pattern.
x Sur Back Assign
(Settings of the surround back
speaker(s))
•OFF
If you have not connected surround back
speakers, select “OFF”.
• BI-AMP
If you connect front speakers in a bi-
amplifier configuration, select “BI-AMP”.
• ZONE2
If you are using the surround back speakers
in zone 2, select “ZONE2”. When you select
“ZONE2”, the input to the SUR BACK jacks
of the MULTI CHANNEL INPUT is invalid.
Note
Set “Sur Back Assign” to “OFF”, then connect the
surround back speakers to this receiver when you
want to change the connection from a bi-amplifier
connection or a zone 2 connection to a surround
back speakers connection. Set up the speakers again
after you connect the surround back speakers. See
“9: Calibrating the appropriate speaker settings
automatically (Auto Calibration)” (page 44) or
“Adjusting the speaker settings manually”
(page 65).
x Crossover Freq
(Speaker crossover frequency)
Lets you set the bass crossover frequency of
speakers that has been set to “SMALL” in the
Speaker settings menu. Measured speaker
crossover frequency is set for each speaker
after the Auto Calibration.
The adjusted value is set for each speaker
when you adjust the speaker crossover
frequency using “Crossover Freq” after the
Auto Calibration.
Test Tone menu parameters Other menu parameters of
Speaker settings
continued

Sony STR-DA3400ES Specifications

General

Equalizer	Yes
Product color	Silver
Frequency range	20 - 20000 Hz
RMS rated power	700 W
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.09 %
Supported radio bands	AM, FM
I/O ports	1 x AV 1 x DM-Port 4 x Audio In 1 x Audio Out 5 x A/V In 1 x A/V Out 1 x S-Video 3 x Component Video In 1 x Component Video Out 1 x Multi-ch In 1 x SW 4 x HDMI In 1 x HDMI Out 4 x Opt. IN 1 x Opt. Out 3 x Coax.
Connectivity technology	Wired
Dimensions (WxDxH)	430 x 388 x 157.5 mm
Power requirements	230 V, 50/60 Hz
HDMI ports quantity	5
Package weight	16000 g
Power consumption (standby)	0.7 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	12500 g
