STR-DE400
SECTION 1
GENERAL
This section is extracted
from instruction manual.
Front panel
AUTO CAL MIC
PHONES
MEMORY
FM MODE TUNING
+
PRESET TUNING
VIDEO 1 VIDEO 2 DVD SA-CD/CD FM AM
AMP MENU ENTER MASTER
VOLUME
INPUT MODE
+
DISPLAY DIMMER
2CH A.F.D. MOVIE MUSIC
?/1
1 5 64 qa9 q; qs qd
qf
8
qlw; qk qgqh
23 7
qj
Name Function
A ?/1 Press to turn the receiver
on or off.
B AUTO CAL MIC
jack
Connects to the supplied
ECM-AC2 optimizer
microphone for the Auto
Calibration function.
C MEMORY Press to store a station.
D PRESET TUNING
+/–
Press to select a preset
station.
E DISPLAY Press to select information
displayed on the display.
F DIMMER Press to adjust the
brightness of the display.
G Remote sensor Receives signals from
remote commander.
Name Function
H Display The current status of the
selected component or a
list of selectable items
appears here.
I AMP MENU Press to display the menu
of the receiver.
J ENTER Press to store a station or
enter the selection when
selecting the settings.
K 2CH Press to select 2CH
STEREO mode.
L A.F.D. Press to select A.F.D.
mode.
M MOVIE,
MUSIC
Press to select sound fields
(MOVIE, MUSIC).
N MASTER
VOLUME
Turn to adjust the volume
level of all speakers at the
same time.
O INPUT MODE Press to select the input
mode when the same
components are connected
to both digital and analog
jacks.
P I/i/U/u After pressing AMP
MENU (I), press I or i
and U or u to select the
settings.
Q Input buttons Press one of the button to
select the component you
want to use.
R TUNING +/– Press to scan a station.
S FM MODE Press to select FM
monaural or stereo
reception.
T PHONES jack Connects to a headphone.
