Sony STR-DE400 Service Manual

41
STR-DE400
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• COILS
uH: µH
• CAPACITORS
uF: µF
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• Accessories are given in the last of this parts
list.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ADCC BOARD
***********
< CAPACITOR >
C2001 1-128-809-11 CERAMIC 100PF 5% 50V
C2002 1-126-160-11 ELECT 1uF 20% 50V
C2003 1-127-882-31 CERAMIC 0.033uF 10% 50V
C2005 1-128-803-11 CERAMIC 33PF 5% 50V
C2006 1-126-160-11 ELECT 1uF 20% 50V
C2008 1-128-806-11 CERAMIC 56PF 5% 50V
C2010 1-127-882-31 CERAMIC 0.033uF 10% 50V
C2011 1-127-880-11 CERAMIC 0.022uF 10% 50V
C2012 1-127-880-11 CERAMIC 0.022uF 10% 50V
C2013 1-126-160-11 ELECT 1uF 20% 50V
C2014 1-124-465-00 ELECT 0.47uF 20% 50V
C2018 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CNP2000 1-784-921-11 PIN, CONNECTOR 4P
< DIODE >
D2013 8-719-991-33 DIODE 1SS133T-72
D2014 8-719-991-33 DIODE 1SS133T-72
< IC >
IC2000 8-759-167-88 IC NJM4565D
< JACK >
J2000 1-820-056-11 SMALL TYPE JACK (AUTO CAL MIC)
< RESISTOR >
R2000 1-247-831-91 CARBON 1K 5% 1/4W
R2001 1-249-429-11 CARBON 10K 5% 1/4W
R2003 1-249-429-11 CARBON 10K 5% 1/4W
R2005 1-247-903-00 CARBON 1M 5% 1/4W
R2006 1-247-831-91 CARBON 1K 5% 1/4W
R2007 1-249-429-11 CARBON 10K 5% 1/4W
R2008 1-247-897-11 CARBON 560K 5% 1/4W
R2010 1-249-429-11 CARBON 10K 5% 1/4W
R2015 1-249-435-11 CARBON 33K 5% 1/4W
R2016 1-249-431-11 CARBON 15K 5% 1/4W
R2017 1-249-421-11 CARBON 2.2K 5% 1/4W
R2018 1-249-418-11 CARBON 1.2K 5% 1/4W
R2019 1-249-421-11 CARBON 2.2K 5% 1/4W
*************************************************************
A-1179-813-A DIGITAL BOARD, COMPLETE (AEP, UK, RU)
A-1185-840-A DIGITAL BOARD, COMPLETE (AUS)
A-1185-841-A DIGITAL BOARD, COMPLETE (KR)
A-1185-848-A DIGITAL BOARD, COMPLETE (TH)
A-1185-849-A DIGITAL BOARD, COMPLETE (TW)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1001 1-126-925-91 ELECT 470uF 20% 10V
C1002 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1004 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1005 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1021 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1022 1-126-925-91 ELECT 470uF 20% 10V
C1031 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1032 1-126-925-91 ELECT 470uF 20% 10V
C1063 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(AEP, UK, RU)
C1064 1-126-947-11 ELECT 47uF 20% 35V
(AEP, UK, RU)
C1100 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1102 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1103 1-126-947-11 ELECT 47uF 20% 35V
C1107 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1108 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1118 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1119 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1120 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1121 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1122 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1123 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1124 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1129 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1130 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1137 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1138 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1139 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1140 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1142 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1147 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1148 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1149 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1206 1-164-227-11 CERAMIC CHIP 0.022uF 10% 16V
C1251 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C1252 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
When indicating parts by reference number,
please include the board name.
DIGITALADCC
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
•Abbreviation
AUS: Australian model
KR : Korean model
RU : Russian model
TH : Thai model
TW : Taiwan model
Ver. 1.2
