Sony STR-DH510 Service Manual

54
STR-DH510
SECTION 6
ELECTRICAL PARTS LIST
CONNECTION BOARD
*****************
< CONNECTOR >
CNP170 1-778-226-21 CONNECTOR, BOARD TO BOARD 6P
CNS170 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
************************************************************
A-1747-286-A DIGITAL BOARD, COMPLETE
***********************
< CAPACITOR >
C2003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2004 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2005 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2007 1-165-746-31 ELECT 22uF 20% 50V
C2011 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2012 1-126-965-91 ELECT 22uF 20% 50V
C2013 1-165-722-11 ELECT 100uF 20% 10V
C2021 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C2022 1-135-372-31 ELECT 470uF 20% 10V
C2023 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2024 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2026 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C2028 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2039 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2041 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2044 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C2048 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C2050 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2051 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2052 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2053 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2054 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2055 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2056 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2057 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2058 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2059 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2060 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2061 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2062 1-117-370-11 CERAMIC CHIP 10uF 10V
C2063 1-126-923-91 ELECT 220uF 20% 10V
C2064 1-126-923-91 ELECT 220uF 20% 10V
C2065 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2069 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2070 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2072 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2073 1-126-923-91 ELECT 220uF 20% 10V
C2074 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2075 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C2076 1-126-923-91 ELECT 220uF 20% 10V
C2077 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2078 1-117-370-11 CERAMIC CHIP 10uF 10V
C2080 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2083 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2084 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2085 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2087 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2088 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2092 1-117-370-11 CERAMIC CHIP 10uF 10V
C2093 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2094 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2095 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2096 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2097 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2098 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2099 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2101 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2104 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2105 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2106 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2109 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2110 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2111 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2112 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2113 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2114 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2115 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C2116 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C2117 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2118 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2119 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2120 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2121 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C2122 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CND : Canadian model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
DIGITAL
CONNECTION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Sony STR-DH510 Specifications

General

AirPlay	No
Display	VFL
Equalizer	Yes
Product color	Black
Audio decoders	Dolby Digital, Dolby Pro Logic II, dts
Apple docking compatibility	Not supported
Impedance	8 Ω
Receiver type	Surround
Frequency range	20 - 20000 Hz
RMS rated power	500 W
Audio output channels	5.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	3
Digital audio optical in	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	-
Headphone connectivity	3.5 mm
AM band range	530 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Power consumption (standby)	0.3 W
Power consumption (typical)	230 W

Weight and Dimensions

Depth	322 mm
Width	430 mm
Height	157.5 mm
Weight	7400 g
