Sony STR-DH510 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH510
5555
C2123 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2124 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2125 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2128 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2129 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2131 1-126-947-11 ELECT 47uF 20% 35V
C2133 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2139 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2140 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2142 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2143 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2144 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C2145 1-117-370-11 CERAMIC CHIP 10uF 10V
C2146 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2147 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2149 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2154 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2155 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2157 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2179 1-126-923-91 ELECT 220uF 20% 10V
C2191 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2192 1-117-370-11 CERAMIC CHIP 10uF 10V
C2199 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2201 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C2202 1-126-947-11 ELECT 47uF 20% 35V
C2292 1-117-370-11 CERAMIC CHIP 10uF 10V
C2351 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2354 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2355 1-126-965-91 ELECT 22uF 20% 50V
C2358 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2359 1-126-916-11 ELECT 1000uF 20% 6.3V
C2361 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2370 1-137-649-31 ELECT 220uF 20% 10V
C2401 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2402 1-126-964-11 ELECT 10uF 20% 50V
C2403 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2404 1-126-964-11 ELECT 10uF 20% 50V
C2405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2406 1-126-964-11 ELECT 10uF 20% 50V
C2421 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2422 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C2423 1-126-963-11 ELECT 4.7uF 20% 50V
C2424 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2425 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2501 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2502 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2503 1-112-079-11 ELECT 220uF 20% 10V
C2504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2505 1-112-079-11 ELECT 220uF 20% 10V
C2506 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2507 1-112-100-11 ELECT 10uF 20% 50V
C2508 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2509 1-112-100-11 ELECT 10uF 20% 50V
C2510 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2511 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C2512 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2513 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2514 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2515 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2516 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2517 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2541 1-112-100-11 ELECT 10uF 20% 50V
C2542 1-112-100-11 ELECT 10uF 20% 50V
C2543 1-112-100-11 ELECT 10uF 20% 50V
C2544 1-112-100-11 ELECT 10uF 20% 50V
C2545 1-126-964-11 ELECT 10uF 20% 50V
C2546 1-126-964-11 ELECT 10uF 20% 50V
C2551 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C2552 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C2553 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C2554 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C2555 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C2556 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C2601 1-126-964-11 ELECT 10uF 20% 50V
C2602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2604 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2609 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2619 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2721 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2722 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2801 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2802 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2803 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2804 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2805 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2807 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2808 1-112-117-11 ELECT 220uF 20% 10V
C2809 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C2810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2811 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C2812 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2813 1-112-077-11 ELECT 1000uF 20% 6.3V
C2814 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2815 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
C2816 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
C2901 1-126-965-11 ELECT 22uF 20% 50V
C2902 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2903 1-165-722-11 ELECT 100uF 20% 10V
C2904 1-126-933-11 ELECT 100uF 20% 16V
C2905 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2906 1-126-933-11 ELECT 100uF 20% 16V
C2907 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2910 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C2911 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C2912 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2913 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2914 1-126-963-11 ELECT 4.7uF 20% 50V
C2915 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C2916 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C2917 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2918 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2919 1-126-963-11 ELECT 4.7uF 20% 50V
C2920 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C2921 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
DIGITAL
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Sony STR-DH510 Specifications

General

AirPlay	No
Display	VFL
Equalizer	Yes
Product color	Black
Audio decoders	Dolby Digital, Dolby Pro Logic II, dts
Apple docking compatibility	Not supported
Impedance	8 Ω
Receiver type	Surround
Frequency range	20 - 20000 Hz
RMS rated power	500 W
Audio output channels	5.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	3
Digital audio optical in	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	-
Headphone connectivity	3.5 mm
AM band range	530 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Power consumption (standby)	0.3 W
Power consumption (typical)	230 W

Weight and Dimensions

Depth	322 mm
Width	430 mm
Height	157.5 mm
Weight	7400 g
