Sony Trinitron PVM-14L2 User Manual

Specifications
32
Remote input terminal
Parallel remote
Modular connector 8-pin (1)
Output
LINE A output connectors
Y/C output 4-pin mini-DIN (1) Loop-through,
with 75 Ω automatic terminal
function
VIDEO output
BNC type (1) Loop-through, with
75 Ω automatic terminal function
AUDIO output
Phono jack (1) Loop-through
LINE B output connectors
VIDEO output
BNC type (1) Loop-through, with
75 Ω automatic terminal function
AUDIO output
Phono jack (1) Loop-through
RGB/Component output connectors (for the PVM-
14L2/PVM-20L2 only)
RGB/Component output
BNC type (3) Loop-through, with
75 Ω automatic terminal function
AUDIO output
Phono jack (1) Loop-through
Externally synchronized output connector
BNC type (1) Loop-through, with
75 Ω automatic terminal function
Built-in speaker output
0.8 W (monaural)
Video signal
Frequency response
PVM-9L3/PVM-9L2
50 Hz to 6 MHz (0 dB/–3 dB)
PVM-14L2/PVM-20L2
50 Hz to 10 MHz (0 dB/–3 dB)
Aperture compensation
1)
OFF: 0 dB
ON: 2 dB to 6 dB
Picture performance
Normal scan 6% overscan of CRT effective screen
area (PVM-9L3/PVM-9L2)
7% overscan of CRT effective screen
area (PVM-14L2/PVM-20L2)
Underscan 5% underscan of CRT effective screen
area
Linearity PVM-9L3/PVM-9L2
H: 4% or less
V: 4% or less
PVM-14L2
H: 4% or less
V: 4% or less
PVM-20L2
H: 5% or less
V: 5% or less
Color temperature
D65, D93, USER (Adjustable color
temperature: 5000 K to 10000 K)
Convergence error
PVM-9L3/PVM-9L2
Center: 0.4 mm (1/32 inch) or less
Peripheral: 0.5 mm (1/32 inch) or
less
PVM-14L2
Center: 0.4 mm (1/32 inch) or less
Peripheral: 0.5 mm (1/32 inch) or
less
PVM-20L2
Center: 0.5 mm (1/32 inch) or less
Peripheral: 0.7 mm (1/32 inch) or
less
Raster size stability
H: 1.0%
V: 1.0%
Resolution (at screen center)
450 TV lines (PVM-9L3)
250 TV lines (PVM-9L2)
600 TV lines (PVM-14L2/PVM-20L2)
Operating conditions
Temperature 0 °C to 35 °C (32 °F to 95 °F)
Humidity 30% to 85% (no condensation)
Pressure 700 hPa to 1060 hPa
Storage and transport conditions
Temperature –10 °C to 40 °C (14 °F to 104 °F)
Humidity 0% to 90%
Pressure 700 hPa to 1060 hPa
Accessories supplied
AC power cord (1)
AC plug holder (1)
Operating Instructions (1)
The PVM-9L3/PVM-9L2/PVM-14L2/PVM-20L2 is a
Trinitron color video monitor for professional use.
Design and specifications are subject to change without
notice.
1) The aperture cannot be compensated for RGB input signals.
