The Installation Menu
The Installation Menu
The Installation menu is used for installing the projector.
Setting items Description
Edge Blending On/Off: When set to “On,” the Edge Blending function is enabled. Set to
“Off” when you do not project using multiple projectors.
Blending
Range
Sets the edge blending width.
After selecting the blending position, a marker will be displayed.
Top: Adjusts the top width of the screen.
Bottom: Adjusts the bottom width of the screen.
Left: Adjusts the left width of the screen.
Right: Adjusts the right width of the screen.
Zone Black
Level Adj.
*1
*2
Adjust so that the overlapped part is not noticeably bright when a dark
image is displayed.
Select the correction zone “Adjust Zone 1” through “Adjust Zone 9,” and
set the adjustment values.
Blend
Gamma
Sets the mode of the gamma curve of the overlapped area.
Mode 1: Provides a gentle gamma correction curve.
Mode 2:
Mode 3:
Mode 4:
Mode 5: Provides a sharp gamma correction curve.
Reset Resets the adjusted values to their default values.
Image Split
Off/Left-side Area/Right-side Area: Divides the input signal from the
computer in half, and displays an enlarged image of the left-side or right-side
area on the screen.
*11
Screen Fitting
*3
HV Keystone/Warping: You can choose the way to correct image twist.
V Keystone
*4 *5
This is displayed when “HV Keystone” is selected in “Screen Fitting.”
The higher the setting, the narrower the top of the projected image. The
lower the setting, the narrower the bottom of the projected image.
H Keystone
*4 *5
This is displayed when “HV Keystone” is selected in “Screen Fitting.”
The higher the setting, the narrower the right side of the projected image.
The lower the setting, the narrower the left side of the projected image.
Warping
*5
This is displayed when “Warping” is selected in “Screen Fitting.”
Adjust: Corrects image twist.
Reset: Resets the adjusted values to their default values.
Image Flip HV/H/V/Off: Flips the projected image horizontally and/or vertically
according to the installation method.
