Specifications
Specifications
Item Description
Model name VPL-FHZ55
Display system 3 LCD system
Display device Size of effective
display area
0.76" (19.3 mm) × 3, Aspect ratio 16:10
Number of pixels 6,912,000 (1920 × 1200 × 3) pixels
Projection lens Zoom Manual (approx.1.6 ×)
Focus Manual
Light source Laser diode
Screen size 40" to 600" (1.02 m to 15.24 m)
Light output 4,000 lm
Displayable
scanning
frequency
*1
Horizontal: 14 kHz to 93 kHz, Vertical: 47 Hz to 93 Hz
Display resolution Computer signal
input
Maximum display resolution: 1920 × 1200 dots
Panel display resolution: 1920 × 1200 dots
Video signal
input
NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/
50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p,
1080/50p, 1080/24p
Color system NTSC
3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N,
PAL60
Computer and
video signal input/
output
INPUT A RGB/YP
BPR input terminal: 5BNC female, G with
sync/Y: 1 Vp-p ± 2 dB, sync negative, 75 ohms
terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB, 75 ohms
terminated, Sync signal: TTL level high impedance,
positive/negative
Audio input terminal: Stereo mini jack, rated input 500
mVrms, input impedance more than 47 kilohms
INPUT B RGB input terminal: Mini D-sub 15-pin female, RGB:
0.7 Vp-p ± 2 dB, 75 ohms terminated, Sync signal: TTL
level high impedance, positive/negative
Audio input terminal: Stereo mini jack, rated input 500
mVrms, input impedance more than 47 kilohms
INPUT C DVI-D input terminal: DVI-D 24-pin (Single link), DVI
1.0 compliant, HDCP support
Audio Input terminal: Shared with INPUT B
INPUT D
*1
HDMI input terminal: Digital RGB/YPBPR, Digital
audio: PCM (32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96
kHz)

Sony VPL-FHZ55 Specifications

General

Native aspect ratio	16:9
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	8000:1
Screen size compatibility	40 - 600 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	30 °
Focus	Manual
Throw ratio	1.4 - 2.3:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	- %
Service life of light source	20000 h
3D	No
Supported video modes	480p, 576p, 720p, 1080i, 1080p
Analog signal format system	NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Noise level	40 dB
Noise level (economic mode)	35 dB
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, VIE
Placement	Desktop
Product type	Large venue projector
Product color	White
Power source	DC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	35 - 85 %
Cables included	AC
Remote control type	IR

Weight and Dimensions

Depth	487 mm
Width	390 mm
Height	134 mm
Weight	11000 g
