Star Micronics TSP143IIU User Manual

– 19 –
6. Control Panel and Other Functions
6-1. Control Panel
1
POWER lamp (Green LED)
3
FEED button
2
ERROR lamp (Red LED)
6-2. Lamp Indicator
1) Printer Status
Status POWER Lamp ERROR Lamp
Printing On O
Print Ready On O
System O
O O
Errors
Refer to next page.
Refer to next page.
Note: Depending on the USB port used, it may take a short time for the printer to enter the
system o mode aer the computer is turned o.
1
POWER lamp (Green LED)
Lights when the power is ON.
Important:
is printer is not equipped with a power
switch. Aer plugging the power cord into
an AC outlet, the printer power will be
turned on for the rst time when the USB
cable is connected to a computer that is
turned on.
2
ERROR lamp (Red LED)
Indicates various errors in combination
with POWER lamp.
3
FEED button
Press the FEED button to feed roll paper.

Star Micronics TSP143IIU Specifications

General

Color	Yes
Print technology	Direct thermal
Maximum print height	8 mm
Standard interfaces	USB
USB 2.0 ports quantity	1
Power consumption	1000 mA
Compatible operating systems	Windows XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit, XP Embedded, CE, POSReady 2009, OPOS, JavaPOS, USB Vendor Class, Linux, Mac OS X, StarIO SDK with support for iOS, Android and Blackberry
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.065 - 0.085 mm
Autocutter durability	1 million cuts
Maximum roll diameter	83 mm
Supported paper width	80, 72, 58, 50.8 mm
Product color	White
Certification	UL, C-UL, TüV, FCC, VCCI, EN55022, CE

Weight and Dimensions

Depth	204 mm
Width	142 mm
Height	132 mm
