18
4) Use the key and the key to view each single measured data in that group
while viewing details.
5) Press the key to return to previous screen at any time during data logging.
5.6.2 Deleting selected file/Group
The user may require deleting a file from the instrument memory. The
procedure is outlined in the following steps.
1) Press the key to activate the data logging function. The memory icon will
appear. It will display the current file name, the test parameter of the group
data and the mean value of the group. If there is no data in the memory, it will
display: <E04>, which means no memory data, and then return back.
2) Use the key and the key to scroll to the file that will be deleted.
3) Press the key on the desired file. It will automatically delete the file, and
display “-DEL”.
4) Press the key, at any time, to exit the data logging function and return to
measurement mode.
Note
：
Do not shut down the instrument while deleting data. It could lead to loss
of all data if shut down while deleting.
5.7 Print Report
At the end of the inspection process, or end of the day, the user may require the
readings be printed.
Before printing, please insert one connection plug of the print cable into the
socket on the upper left side of the main body, and insert the other plug into the
communication socket of your PC. You can print out the measurement result
immediately after each testing process, by easily pressing the key.
If you want to print the data stored in the instrument memory, then follow
these steps:
1. Press the key to activate the data logging function. The memory icon will
appear.
2. Use the key and the key to select the desired file.
3. Press the key to print the selected file. This operation will send all the data in
current file to the mini printer via RS232 port and print them out.
4. Press the key to exit the data logging functions and return to measurement
mode.
5.8 System Reset
Press down the key while powering on the instrument will restore
factory defaults. The only time this might possibly helpful is if one of the parameters
in the gauge were somehow corrupted.
5.9 Backlight
With the background light, it is convenient to work in darker conditions.
