47EN
5. OPERATION
5.3.8.
To start up the robot lawn mower, follow the procedure described in Par. 5.3.4 “SCHEDULED PROGRAM
SELECTION / SINGLE WORK CYCLE / FORCED RETURN TO CHARGING BASE - MODE SELECTION
BUTTON".
5.4.
The charging base is provided with a warning light (N) that lights up as follows:
• Warning light o : the charging base is powered o or the robot is on the base;
• Fixed warning light: the robot lawn mower is not connected to the charging base and the antenna
signal is correctly transmitted;
• Flashing light: there is a fault in the charging base.
N
5.5.
The "" procedure allows to recharge the robot lawn mower manually.
• Charging base connected to the mains.
1. Position the robot lawn mower on the charging base (R).
2. Slide the robot lawn mower onto the charging base, until the charging connector (S) is engaged.
3. Press the button “STOP” (A) to open the cover (B) and access the control console (C).
4. Turn the robot lawn mower on with the “” button (E).
5. When the “BATTERY” icon (O) ashes blue, the robot lawn mower is charging.
6. Close the cover (B).
7. Leave the robot lawn mower to charge for at least the time shown in Par. 4.5.3.
NOTE: Charging the battery before winter storage should be carried out as shown in Par. 6.4.
R
A BC
S
E
O
