Stiga Stig-A 1500 User Manual

2 EN
1. MODELS AND TECHNICAL DATA
1.2. 
SPECIFICATIONS
UNIT OF
MEASURE

1500

3000

5000
Dimensions (WxHxD)
[mm] 413 x 252 x 560 529 x 299 x 695 529 x 299 x 695
Weight of the robot lawn mower
[kg] 8.5 12.5 13
Cutting height (Min-Max)
[mm] 20-60 20-65 20-65
Blade diameter
[mm] 180 260 260
Cutting speed
[rpm] 2850+/-50 2400+/-50 2400+/-50
Speed of movement
[m/min] 22 24 24
Maximum slope
[%] 45 50 50
Maximum slope along the perimeter
[%] 20 20 20
Type of electric traction motor
- Brushless Brushless Brushless
Type of cutting system
- 4 pivoting cutting
blades
6 pivoting cutting
blades
6 pivoting cutting
blades
Cutting device code
- 322104105/0 322104105/0 322104105/0
Type of electric cutting motor
- Brushless Brushless Brushless
Sound power level detected
[dB] (A) 57 56 56
Uncertainty of noise emissions, KWA
[dB] (A) 1.47 0.56 0.56
Sound power level guaranteed
[dB] (A) 59 57 57
Acoustic level audible by the operator
[dB] (A) 46.3 45.2 45.2
IP rating of the robot lawn mower
- IPX5 IPX5 IPX5
IP rating of the charging station
- IPX1 IPX1 IPX1
IP rating of the power supply
- IP67 IP67 IP67
Robot lawn mower operating ambient
temperature [° C]
[°C] 0 - 50 0 - 50 0 - 50
Charging station operating ambient
temperature [° C]
[°C] -10 - 50 -10 - 50 -10 - 50
Power supply ambient operating
temperature [° C]
[°C] -10 - 50 -10 - 50 -10 - 50
Work capacity
[m²] 1500 3000 5000
Power supply
- Input: 100-240vac
1.2 A
Output: 30Vcc 2A
Input: 100-240Vac
1.2A
Output: 30Vcc 2A
Input: 100-240vac
0.65 A
Output: 30Vcc 4A
Battery model
- 25.2 V-5Ah 25.2 V-5Ah 25.2V 2 x 5Ah
Charging time
[min] 150 150 150
Bluetooth
- 4.2 4.2 4.2
