Stiga VILLA 2003 User Manual

Edition Manual Chapter Page
2008-05-19 Workshop Manual, Stiga Villa/Ready 1 General 13
1.5.4 Description of service points
Models with manual gearbox
Test Status Action Result
1 PTO activated.
No gear activated.
Turn the key and make a
start attempt.
Motor shall not
start.
2 PTO not activated.
A gear is activated.
Turn the key and make a
start attempt.
Motor shall not
start.
3 Motor running.
PTO activated.
Operator rises from the
seat.
Motor shall
stop.
4 Motor running.
A gear activated.
Operator rises from the
seat.
Motor shall
stop.
5 Motor running. Disconnect cable from the
shut off valve.
Motor shall
stop after a few
minutes.
HST models
Test Status Action Result
1 Brake pedal not pressed.
PTO not activated.
Turn the key and make a
start attempt.
Motor shall not
start.
2 Brake pedal pressed.
PTO activated.
Turn the key and make a
start attempt.
Motor shall not
start.
3 Motor running.
PTO activated.
Operator rises from the
seat.
Motor shall
stop.
4 Motor running. Disconnect cable from the
shut off valve.
Motor shall
stop after a few
minutes.
1. Safety check
Check the safety functions. It is often appropriate to do this check in conjunction with test
driving. The following items shall be checked at all machines:
• No leakage on fuel lines and connections.
• No mechanical damages to the electrical cables. All insulation intact.
• The muffler shall be undamaged and its screws tightened. No exhaust leakage in con-
nections.
The electrical check items at the respective machine up to model 2004 are listed in the
tables below. For models 2005 and up, see the respective “Instructions for use”.

Stiga VILLA 2003 Specifications

General

Brand	Stiga
Model	VILLA 2003
Category	Lawn Mower
Language	English
