Edition Manual Chapter Page
2008-05-19 Workshop Manual, Stiga Villa/Ready 7 Electrical System 3
7.2 Trouble Shooting
Warning!
Do not wear rings, metallic bracelet, chain round the neck or similar metal
objects when working with the electrical system. It can cause short-circuit,
burns and fire.
This section describes the trouble shooting procedures in absence of an electrical function.
It also describes the correction measures in each actual case. When following the trouble
shooting schedules, it is provided that the following states are fulfilled:
• All fuses are checked and, if necessary replaced.
• The battery shall be charged.
• The requirements for the actual measure shall be fulfilled. E.g. if it is advised to perform a
start attempt, the operator shall sit down on the seat, press the brake pedal and the
power take off shall be in disengaged position.
When following the trouble shooting shedules, it is in normal cases assumed that
conductors and connectors to conductors are OK. However, in some cases, after a long
period of use or in case of mechanical damages, the cables at the articulating point can be
damaged. The circuit diagrams are presented in the respective spare parts manual.
The following operation faults for models 2002-2007 are described.
Paragraph Page
7.2.1 The starter does not rotate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
7.2.2 The starter rotate, but the motor does not start . . . . . . . . . . . . . .8
7.2.3 The battery runs repeatedly empty . . . . . . . . . . . . . . . . . . . . . . .10
7.2.4 The motor does not stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.2.5 Electric cutting height adjustment . . . . . . . . . . . . . . . . . . . . . . . .12
7.2.6 The PTO clutch does not engage . . . . . . . . . . . . . . . . . . . . . . . .12
7.2.7 The motor can be started without the brake pedal is pressed . . 13
7.2.8 The motor can be started with the mover deck activated . . . . . .13
7.2.9 The motor can be started with a gear activated . . . . . . . . . . . . .13
7.2.10 The motor does not stop when the operator leaves
the seat and the mover deck is activated . . . . . . . . . . . . . . . . . .14
7.2.11 The PTO clutch does not disengage when the operator
leaves the seat and the mover deck is activated . . . . . . . . . . . . .14
7.2.12 The motor does not stop after a few minutes
when the shut off valve cable is disconnected . . . . . . . . . . . . . .15
