System Manual 5 Mechanical Installation
27
5.4 Removing Flashings and Cover Plates
The flashings and cover plates are attached to the enclosure of the MV Station to prevent
moisture penetration during transportation. Locations of the flashings and cover plates are
shown by A and B respectively in the figure below. Remove the flashings and cover plates
before commissioning.
B
B
B
B
B
B
B
B
A
A
A
A
A
A
A A A
A A
Front view
Left view
Back view
Right view
A A
B
B
B
B
The cover plate and the flashings are heavy; therefore, please make sure this
procedure is performed by at least two persons.
