Suzuki DF 2.5 Service Manual

MID UNIT 7-5
INSPECTION
NOTE:
If excessive wear, crack, defective or other damage is found on
any component, replace.
DRIVESHAFT HOUSING
If crack or other damage is found, replace.
CLAMP BRACKET/SWIVEL BRACKET
Inspect the clamp brackets and swivel bracket.
If crack or other damage is found, replace.
STEERING UPPER BUSHING
Inspect the upper bushings.
If crack, excessive wear, deterioration or other damage is found,
replace.
STOPPER BRACKET/STOPPER SPRING
Inspect the stopper bracket and the stopper spring.
If crack or other damage is found, replace.
THRUST BLOCK/LOWER THRUST MOUNT
Inspect the thrust block and the lower thrust mount.
If crack, excessive wear, deterioration or other damage is found,
replace.

Suzuki DF 2.5 Specifications

General

Engine Type	OHV
Fuel System	Carburetor
Starting System	Manual
Engine Mounting	Bushing Type
Gear Ratio	2.15:1
Gear Shift	F-N
Exhaust	Above Prop Exhaust
Maximum Output	1.8 kW (2.5 PS)
Ignition System	CDI
Fuel Tank Capacity	1.0 L
Weight	13.5 kg
Full Throttle Operating Range	5, 250 rpm
Trim Method	Manual
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
