FUEL SYSTEM 4-13

FUEL TANK AND FUEL COCK

REMOVAL

1. Remove the motor cover.

2. Remove the recoil starter 1. (See page 5-2.)

3. Turn the fuel cock lever 2 “OFF” position.

4. Remove the fuel hose 3 from the fuel cock 4.

5. Remove the fuel tank 5.

6. Loosen the screw 6.

Remove the fuel cock 4 from the fuel tank.

Questions and Answers:

Need help?

Do you have a question about the Suzuki DF 2.5 and is the answer not in the manual?

Suzuki DF 2.5 Specifications

General

Engine Type	OHV
Fuel System	Carburetor
Starting System	Manual
Engine Mounting	Bushing Type
Gear Ratio	2.15:1
Gear Shift	F-N
Exhaust	Above Prop Exhaust
Maximum Output	1.8 kW (2.5 PS)
Ignition System	CDI
Fuel Tank Capacity	1.0 L
Weight	13.5 kg
Full Throttle Operating Range	5, 250 rpm
Trim Method	Manual
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
