3-2 IGNITION AND ELECTRICAL
IGNITION SYSTEM
OUTLINE
A transistorized ignition system is employed on the DF2.5.
This system consists of flywheel magneto, igniter unit, spark plug and emergency/engine stop switch.
SPECIFICATIONS
Ignition type Transistorized ignition
Ignition timing BTDC 30°
Flywheel magneto
Igniter unit
Spark plug
Emergency/engine stop switch

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki DF 2.5 and is the answer not in the manual?

Suzuki DF 2.5 Specifications

General IconGeneral
Engine TypeOHV
Fuel SystemCarburetor
Starting SystemManual
Engine MountingBushing Type
Gear Ratio2.15:1
Gear ShiftF-N
ExhaustAbove Prop Exhaust
Maximum Output1.8 kW (2.5 PS)
Ignition SystemCDI
Fuel Tank Capacity1.0 L
Weight13.5 kg
Full Throttle Operating Range5, 250 rpm
Trim MethodManual
Bore x Stroke48 x 38 mm (1.9 x 1.5 in.)
