2-10 PERIODIC MAINTENANCE

INSTALLATION

Installation is reverse order of removal with the special attention

to the following steps.

• Tighten the four cylinder head cover bolts diagonally to the

specified torque.

 Cylinder head cover bolt: 7 N·m (0.7 kg-m, 5.0 lb-ft)



• Make sure that the cylinder head cover gasket is installed cor-

rectly.

Do not re-use the removed gasket. Always use a new

gasket.

Questions and Answers:

Need help?

Do you have a question about the Suzuki DF 2.5 and is the answer not in the manual?

Suzuki DF 2.5 Specifications

General

Engine Type	OHV
Fuel System	Carburetor
Starting System	Manual
Engine Mounting	Bushing Type
Gear Ratio	2.15:1
Gear Shift	F-N
Exhaust	Above Prop Exhaust
Maximum Output	1.8 kW (2.5 PS)
Ignition System	CDI
Fuel Tank Capacity	1.0 L
Weight	13.5 kg
Full Throttle Operating Range	5, 250 rpm
Trim Method	Manual
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
