Suzuki DF 2.5 Service Manual

4-4 FUEL SYSTEM
INSTALLATION
Installation is reverse order of removal with the special attention
to the following steps.

• Tighten the carburetor mounting bolts to the specified torque.
 Carburetor mounting bolt: 10 N·m (1.0 kg-m, 7.0 lb-ft)
Throttle control cable installation and adjustment
(See page 4-6.)
CHECK FOR FUEL LEAKAGE
1. Twist the air-vent screw 1 on the fuel tank cap counter-
clockwise to open the vent.
2. Turn the fuel cock lever “ON” position.
3. Check the fuel line for leaks.
Do not re-use the removed gasket. Always use a new
gasket.

Suzuki DF 2.5 Specifications

General

Engine Type	OHV
Fuel System	Carburetor
Starting System	Manual
Engine Mounting	Bushing Type
Gear Ratio	2.15:1
Gear Shift	F-N
Exhaust	Above Prop Exhaust
Maximum Output	1.8 kW (2.5 PS)
Ignition System	CDI
Fuel Tank Capacity	1.0 L
Weight	13.5 kg
Full Throttle Operating Range	5, 250 rpm
Trim Method	Manual
Bore x Stroke	48 x 38 mm (1.9 x 1.5 in.)
