Suzuki DF200 Service Manual

2-22 PERIODIC MAINTENANCE
ANODES
ANODES
If 2/3 of zinc anode has corroded away, replace anode.
The anode should be periodically cleaned with a wire brush to
ensure maximum effectiveness.
NOTE:
The anode cover may be separated from the power unit body by
inserting and turning a 10 mm bolt it to function as a screw jack.
#
NOTE:
The anode securing bolt should be covered with SUZUKI SILI-
CONE SEAL.
& 99000-31120: SUZUKI SILICONE SEAL
Inspect every 50 hours (3 months).
STBD cylinder
1. Screw jack
2. Anode cover
1
2
Never paint the anode.
Anode
PORT cylinder

Suzuki DF200 Specifications

General

Bore x Stroke	97 mm x 97 mm
Maximum Output	200 HP
Fuel Delivery System	Multi-Point Sequential Electronic Fuel Injection
Starting System	Electric
Gear Ratio	2.29:1
Number of Cylinders	4
Maximum Output (kW)	147 kW
Steering	Remote
Max Power	200 HP
Trim Method	Power Trim and Tilt
Exhaust	Through Prop Hub Exhaust
Displacement	2, 867 cc
Weight	226 kg
Full Throttle Operating Range	5, 500 - 6, 100 rpm
Oil Capacity	8.0 L
Full Throttle RPM Range	5500 - 6100 RPM
Shaft Length	20 inches, 25 inches
Alternator Output	44 A
Engine Type	4-Stroke DOHC 16-Valve
