5B-31 Manual Transmission/Transaxle:
Specifications
Tightening Torque Specifications
S5JB0A5207001
NOTE
The specified tightening torque is also described in the following.
“Manual Transmission Assembly Components: ”
“Gear Shift Control Lever Rear Case Assembly Components: ”
“Gear Shift Lever Front Case Assembly Components: ”
“Gear Shift Shaft and Fork Components: ”
“Input Shaft Assembly, Output Shaft Assembly and Countershaft Assembly Components: ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fastener Information: in Section 0A”.
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Transmission oil drain plug 23 2.3 17.0 )
Oil filler plug 23 2.3 17.0 )
Control lever locating bolt 9 0.9 6.5 )
Case cover bolt 10 1.0 7.5 )
Control lever boot cover bolt 12 1.2 9.0 )
Back up light switch 23 2.3 17.0 )
Plate bolt 23 2.3 17.0 )
Control shaft joint nut 18 1.8 13.0 ) / )
Gear shift lever front case bolt 23 2.3 17.0 )
Engine rear mounting No.1 bolt 55 5.5 40.0 )
Engine rear mounting member bolt 55 5.5 40.0 ) / )
Engine rear mounting No.2 bolt 55 5.5 40.0 ) / )
Transmission to engine bolt and nut 85 8.5 61.5 )
Clutch housing lower plate bolt 11 1.1 8.0 )
Low gear shift inverse lever bolt 23 2.3 17.0 )
Transmission case bolt 23 2.3 17.0 )
Reverse shaft bolt 23 2.3 17.0 )
Gear shift locating bolt 23 2.3 17.0 )
Adapter case bolt 23 2.3 17.0 )
Input shaft 5th hub nut 210 21.0 152.0 )
Countershaft front bearing nut 210 21.0 152.0 )
