5A-78 Automatic Transmission/Transaxle:
Reference Waveform No. 5
Input shaft speed sensor signal at engine speed 3000
rpm.
TCM Power and Ground Circuit Check
S5JB0A5104062
Wiring Diagram
Measurement
terminal
CH1: “E93-6” to “E92-1”
Oscilloscope
setting
CH1: 2 V/DIV
TIME: 10 ms/DIV
Measurement
condition
• After warmed up to normal
operating temperature
• Engine at 3,000 rpm with “P”
range.
I5JB0A510047-02
BLK
BLK
BLK
E92-1
E92-23
E92-6
BLK/WHT
BLK/WHT
WHT/GRN
E92-24
WHT
1
2
3
4
7
6
5
65
16 15 14 13 12 11
43
24 23 2122
10 9 8 7
21
1920 18 17
E92
17 16
26 25
15 14
65 342
13 12
23 2224
11 10 9
21 20 19
87
18
1
E93
8
I5JB0A510152-01
1. TCM 5. Ignition switch
2. A/T relay 6. “IG COIL” fuse
3. “AT” fuse 7. Power integration No.2 in main fuse box
4. “DOME” fuse 8. Terminal arrangement of TCM connector (viewed from harness side)
To Next Page
