5A-4 Automatic Transmission/Transaxle:
Item Specifications
Tor qu e
converter
Type 3-element, 1-step, 2-phase type (with TCC (lock-up) mechanism)
Stall torque ratio 2.05
Oil pump
Type Trochoid type oil pump
Drive system Engine driven
Gear
change
device
Type Forward 4-step, reverse 1-step planetary gear type
Shift position “P” range Gear in neutral, output shaft fixed, engine start
“R” range Reverse
“N” range Gear in neutral, engine start
“D” range Forward 1st ↔ 2nd ↔ 3rd ↔ 4th (O/D)
automatic gear change
“D” range (Transfer 4L) Forward 1st ↔ 2nd ↔ 3rd gear change
“3” range Forward 1st ↔ 2nd ↔ 3rd automatic gear
change
“2” range (Normal
mode)
Forward 1st ↔ 2nd ← 3rd automatic gear
change
“2” range (Power mode) Forward 2nd ← 3rd automatic gear change
“L” range Forward 1st ← 2nd reduction, and fixed at 1st
gear
Gear ratio 1st 2.826
2nd 1.493
3rd 1.000
4th 0.688
Reverse 2.703
Control elements Wet type multi-disc clutch ... 3 sets
Wet type multi-disc brake ... 4 sets
One-way clutch ... 3 sets
Transfer Hi: 1.000
Lo: 1.970
Final gear reduction ratio 5.125
Lubrication Lubrication system Forced feed system by oil pump
Cooling Cooling system Radiator assisted cooling (water-cooled)
Fluid used SUZUKI ATF 3317 or Mobil ATF 3309
