CHASSIS 7-59
•
Tighten the rear axle housing bolts/nuts
1
and rear shock
absorber mounting bolt
2
to the specified torque.
Rear shock absorber mounting nut (lo
wer):
60 N·m (6.0 kgf-m, 43.5 lb-ft)
•
Tighten the axle housing mounting nuts
3
.
•
Install the trailer towing. (
See below)
A
Hole
Hole
Clearance
T
railer towing
Align the hole of the trailer towing with
the projection on the rear axle housing.
VIEW OF A
Projection
222
224
