3
The photograph shown indicate the parts dismounted
from the motorcycle in addition to the items shown in
the preceding page.
A: Throttle assembly
Engine stop switch assembly
Clutch cable
SPARE PARTS
Item Part Name Q’ty
1 Cylinder head O-ring No.1 2
2 Cylinder head O-ring No.2 2
3 Exhaust pipe O-ring 2
4 Cylinder cover gasket No.1 2
5 Cylinder cover gasket No.2 1
6 Cylinder gasket 2
7 Crankcase gasket 1
8 Clutch cover gasket 1
9 Piston complete 1
0 Piston ring 2
A Piston pin bearing 1
B Piston pin 1
C Piston pin circlip 2
D Exhaust valve rod bush 2
E Brake lever 1
F Clutch lever 1
To Next Page
